Description
The Trendnet TEG-30284 managed switch, in a 1U format with a black finish, offers 24 Gigabit Ethernet ports (10/100/1000) for copper cabling and 4 SFP+ slots for 10G links, with support for link aggregation and flow control. Its web-based management includes QoS features, 256 VLANs (with support for private and tagged VLANs), spanning tree protocol, and port mirroring, in addition to operating in full duplex. The MAC address table reaches 16,000 entries, facilitating the management of networks with multiple connected devices. With these specifications, this switch allows for the deployment of a scalable and monitorable network infrastructure for professional environments.
Specifications
Management features
- Switch type: Managed
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 24
- SFP+ module slots quantity: 4
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3
- 10G support: Yes
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
- Virtual LAN features: Private VLAN, Tagged VLAN
- Number of VLANs: 256
Data transmission
- Switching capacity: 128 Gbit/s
- Throughput: 95.2 Mpps
- MAC address table: 16000 entries
- Jumbo frames support: Yes
- Jumbo frames: 10000
Security
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Security algorithms: 802.1x RADIUS, HTTPS, SSL/TLS
- MAC address filtering: Yes
- SSH/SSL support: Yes
- Authentication: Port-based authentication
Multicast features
- Multicast support: Yes
Protocols
- Management protocols: SNMP (v1, v2c, v3)
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: Yes
- Number of fans: 1 fan(s)
Performance
- Compatible operating systems: Windows 10, 8.1, 8, 7, Vista, XP, Windows 2003 / 2008 Server
- Noise level: 50 dB
- Buffer size: 2048 KB
- Maximum data transfer rate: 20000 Mbit/s
- Mean time between failures (MTBF): 450021 h
Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 25 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
- Width: 440 mm
- Depth: 210 mm
- Height: 44.5 mm
- Weight: 2.64 kg
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Packaging data
- Resource CD: Yes
Certificates
- Certification: CE FCC UL
Logistics data
- Harmonized System (HS) code: 85176990
