Name: TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+
Brand: TP-LINK
Price: 122.83 USD
Availability: InStock

TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+

$122.83

$122.83 without VAT

TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+. More info

Amount

Brand: TP-LINK

SKU: 78648 PRC: 153132 EAN: 6935364098865 PN: TL-SG1016PE

Description

Specifications

Management features

Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Web-based management: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 16
Power connector: AC-in jack

Network

Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support: No
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6
Port mirroring: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
VLAN support: Yes
Virtual LAN features: Tagged VLAN, Port-based VLAN
Number of VLANs: 4000

Data transmission

Switching capacity: 32 Gbit/s
Forwarding rate: 23.8 Mpps
MAC address table: 8000 entries
Store-and-forward: Yes
Number of queues: 4
Jumbo frames support: Yes
Jumbo frames: 10000
Packet buffer memory: 4.1 MB

Security

IGMP snooping: Yes

Design

Rack mounting: Yes
Stackable: No
Form factor: 1U
Product colour: Black
Housing material: Metal
LED indicators: Yes
Number of fans: 1 fan(s)

Performance

Compatible operating systems: Windows
Maximum cable length: 100 m

Power

Power source: AC/PoE
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 124.4 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 8
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 110 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Weight & dimensions

Width: 294 mm
Depth: 180 mm
Height: 44 mm

Packaging content

Cables included: AC
User guide: Yes
Rack mount kit: Yes

Packaging data

Package type: Box
Resource CD: Yes
Package width: 250 mm
Package depth: 400 mm
Package height: 80 mm
Package weight: 2.28 kg

Sustainability

Sustainability compliance: Yes

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+

Description

Specifications

Management features

Ports & interfaces

Network

Data transmission

Security

Design

Performance

Power

Power over Ethernet (PoE)

Operational conditions

Weight & dimensions

Packaging content

Packaging data

Sustainability

Certificates
