Name: D-Link 26-Port PoE+ Gigabit Smart Managed Switch
Brand: D-LINK
Price: 378.01 USD
Availability: InStock

D-Link 26-Port PoE+ Gigabit Smart Managed Switch

$378.01

$378.01 without VAT

D-Link 26-Port PoE+ Gigabit Smart Managed Switch. More info

Amount

Brand: D-LINK

SKU: 86555 PRC: 305473 EAN: 790069453342 PN: DGS-1100-26MPV2

Description

Specifications

Management features

Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Web-based management: Yes
ARP inspection: Yes
MIB support: • RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC190

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 2

Network

Networking standards: IEEE 802.1D, IEEE 802.1w, IEEE 802.3af, IEEE 802.3at
Copper ethernet cabling technology: 10GBASE-T, 1000BASE-T
Port mirroring: Yes
Full duplex: Yes
Half duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Head-of-line (HOL) blocking: Yes
Auto-negotiation: Yes
VLAN support: Yes
Virtual LAN features: Port-based VLAN, Voice VLAN

Data transmission

Switching capacity: 52 Gbit/s
Forwarding rate: 38.69 Mpps
MAC address table: 8000 entries
Jumbo frames support: Yes

Security

DHCP features: DHCP client
IGMP snooping: Yes
Security algorithms: SSL/TLS
MAC address filtering: Yes
Static port security: Yes

Multicast features

Multicast support: Yes
IPv4 multicast entries: 1
IPv6 multicast entries: 1
Number of multicast groups filtered: 1

Protocols

IPv4 & IPv6 features: IPv4 FIB

Design

Rack mounting: Yes
Product colour: Black
Housing material: Metal

Performance

Flash memory: 16 MB
Noise level: 50.5 dB
Fanless: Yes

Power

Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 454.1 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 24
Power over Ethernet plus (PoE+) ports quantity: 24
Total Power over Ethernet (PoE) budget: 370 W

Operational conditions

Operating temperature (T-T): -10 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Heat dissipation: 287 BTU/h

Weight & dimensions

Width: 440 mm
Depth: 208 mm
Height: 44 mm
Weight: 2.8 kg

Logistics data

Harmonized System (HS) code: 85176990
