Description
LevelOne managed L2/L3/L4 switch in black, with 8 Gigabit Ethernet ports (10/100/1000) and 2 SFP slots for fibre uplinks, also integrates PoE power on its copper ports to simplify cabling. On the management side, it offers web-based administration, support for QoS, VLAN, flow control and rate limiting, along with features such as port mirroring, ARP inspection and storm control to keep the network stable. This model includes event logging on the system and MIB support, which facilitates monitoring and diagnosis of the infrastructure. Its advanced switching layer allows precise traffic segmentation and prioritisation, adapting to corporate environments requiring detailed network control.
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3/L4
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- ARP inspection: Yes
- System event log: Yes
- MIB support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP module slots quantity: 2
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Port mirroring: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Spanning tree protocol: Yes
- Fast leave: Yes
- VLAN support: Yes
- Virtual LAN features: Tagged VLAN, Port-based VLAN
Optical fiber
- Fiber ethernet cabling technology: 1000BASE-X
Data transmission
- Switching capacity: 20 Gbit/s
- Forwarding rate: 14.9 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
- Number of queues: 8
- Jumbo frames support: Yes
- Jumbo frames: 10000
- Packet buffer memory: 4.1 MB
Security
- DHCP features: DHCP client
- Access Control List (ACL): Yes
- Access Control List (ACL) ingress: 256
- IGMP snooping: Yes
- Security algorithms: SSH, SSH-2, SSL/TLS
- MAC address filtering: Yes
- Static port security: Yes
- Loop protection: Yes
- BPDU filtering/protection: Yes
- Root protection: Yes
- Password protection: Yes
- DoS attack prevention: Yes
- Authentication type: HWTACACS+, RADIUS
- CPU defense: Yes
- Queue scheduling algorithms: Weighted Round Robin (WRR)
- Neighbor discovery snooping: Yes
Multicast features
- Multicast Listener Discovery (MLD) snooping: Yes
Protocols
- Management protocols: SNMP v1/v2c/v3, Telnet
- IPv4 & IPv6 features: IPv6 ping, IPv6 tracert, IPv6 Telnet, Dual stack IPv4/IPv6
Design
- Rack mounting: Yes
- Product colour: Black
- Reset button: Yes
- LED indicators: Activity, Link, Power, System
- Safety: UL
Performance
- Internal memory: 16 MB
- Noise level: 0 dB
- Firmware upgradeable: Yes
- Plug and Play: Yes
- Mean time between failures (MTBF): 118824 h
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (typical): 80 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 8
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 70 W
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Operating relative humidity (H-H): 10 - 90%
- Heat dissipation: 267.95 BTU/h
Weight & dimensions
- Width: 294 mm
- Depth: 180 mm
- Height: 44 mm
- Weight: 2 kg
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Packaging data
- Package type: Box
- Resource CD: Yes
- Package width: 375 mm
- Package depth: 270 mm
- Package height: 85 mm
- Package weight: 2.18 kg
Certificates
- Certification: CE class A, FCC, VCCI, BSMI
Logistics data
- Country of origin: China
- Harmonized System (HS) code: 85176990
