Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
- Traffic classification: Yes
- System event log: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Combo SFP ports quantity: 2
- Fiber ports quantity: 2
- Fiber optic connector: SFP
- Console port: RJ-45
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.
- 10G support: No
- Port mirroring: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Spanning tree protocol: Yes
- Cable length detection: Yes
- VLAN support: Yes
- Virtual LAN features: MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Tagged VLAN
- Number of VLANs: 4000
Optical fiber
- Fiber ethernet cabling technology: 100BASE-X, 1000BASE-X
Data transmission
- Switching capacity: 20 Gbit/s
- Forwarding rate: 14.9 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
- Number of trunks: 8
- Number of queues: 8
- Static route: Yes
- Jumbo frames support: Yes
- Jumbo frames: 10000
- Packet buffer memory: 4.1 MB
Security
- DHCP features: DHCP client, DHCP snooping
- Access Control List (ACL): Yes
- Access Control List (ACL) rules: 512
- IGMP snooping: Yes
- MAC address filtering: Yes
- SSH/SSL support: Yes
- BPDU filtering/protection: Yes
- Password protection: Yes
- DoS attack prevention: Yes
Multicast features
- Multicast support: Yes
Protocols
- IPv4 & IPv6 features: IPv6 Telnet, IPv6 ping, IPv6 tracert
Design
- Rack mounting: Yes
- Stackable: No
- Product colour: Black
- Reset button: Yes
- LED indicators: Activity, Link, Power
Performance
- Internal memory: 32 MB
- Noise level: 0 dB
- Telnet: Yes
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (typical): 80 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 8
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 125 W
Operational conditions
- Operating temperature (T-T): -10 - 50 °C
- Storage temperature (T-T): -40 - 85 °C
- Operating relative humidity (H-H): 10 - 95%
Weight & dimensions
- Width: 181 mm
- Depth: 270 mm
- Height: 44 mm
- Weight: 800 g
Packaging content
- Cables included: AC, LAN (RJ-45)
- Quick start guide: Yes
- Rack mount kit: Yes
Packaging data
- Package type: Blister
- Resource CD: Yes
- Package width: 255 mm
- Package depth: 82 mm
- Package height: 345 mm
- Package weight: 2 kg
Certificates
- Certification: CE class A, FCC, UL, VCCI, BSMI
Logistics data
- Country of origin: China
- Harmonized System (HS) code: 85176990
