Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 8
- Power connector: AC-in jack
Network
- Networking standards: IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support: No
- Port mirroring: Yes
- Full duplex: Yes
- Half duplex: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
- VLAN support: Yes
- Number of VLANs: 32
Data transmission
- Switching capacity: 16 Gbit/s
- Forwarding rate: 11.904 Mpps
- MAC address table: 4000 entries
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Packet buffer memory: 1.5 MB
Security
- IGMP snooping: Yes
Design
- Product colour: Black
- LED indicators: Activity, Link, Power
- Rack mounting: Yes
- Stackable: No
Performance
- Flash memory: 2 MB
- Noise level: 0 dB
- Fanless: Yes
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Power consumption (typical): 6 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 95%
- Heat dissipation: 20.4 BTU/h
Weight & dimensions
- Width: 215 mm
- Depth: 150 mm
- Height: 44.5 mm
- Weight: 720 g
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Packaging data
- Package type: Box
- Package width: 285 mm
- Package depth: 257 mm
- Package height: 62 mm
- Package weight: 1.19 kg
Certificates
- Certification: CE, UKCA, FCC Part 15, Subpart B Class B, RoHS
Logistics data
- Country of origin: China
