Description
The D-Link DXS-1210-12SC managed switch is an L2/L3 device in 1U format, in black and silver, with dimensions of 440 x 44 x 210 mm (width x height x depth) and a weight of 2.72 kg. It incorporates ten slots for SFP+ modules and two combo SFP ports, which facilitates fibre optic connection via SFP+ connectors. It has an RJ-45 console port for configuration and administration. Its management is carried out through a web interface, and it includes MIB support and QoS quality of service functions. It offers VLAN support, port mirroring, ARP inspection, storm transmission control and flow control. In addition, it implements spanning tree and link aggregation protocols, and complies with the IEEE 802.3ab, 802.3bz, 802.3ae, 802.3an, 802.3u, 802.3z and 802.3az network standards. All of this with 10G support for your high-speed connections.
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- ARP inspection: Yes
- MIB support: Yes
Ports & interfaces
- Combo SFP ports quantity: 2
- SFP+ module slots quantity: 10
- Fiber optic connector: SFP+
- Console port: RJ-45
Network
- Spanning tree protocol: Yes
- Head-of-line (HOL) blocking: Yes
- Ethernet LAN data rates: 1000,5000,100,2500,10000 Mbit/s
- VLAN support: Yes
- Number of VLANs: 4094
- Networking standards: IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3z, IEEE 802.3az
- 10G support: Yes
- Cable types supported: Cat6a, Cat7
- Port mirroring: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Auto MDI/MDI-X: Yes
Data transmission
- Switching capacity: 240 Gbit/s
- Forwarding rate: 178.56 Mpps
- MAC address table: 32000 entries
- Store-and-forward: Yes
- Number of queues: 8
- Jumbo frames support: Yes
- Jumbo frames: 10000
Security
- DHCP features: DHCP client, DHCP server
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Loop protection: Yes
- Password protection: Yes
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Product colour: Black, Silver
- LED indicators: Yes
- Number of fans: 2 fan(s)
Performance
- Noise level: 46.3 dB
Power
- Power source: AC
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Power consumption (max): 27.4 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
Weight & dimensions
- Width: 440 mm
- Depth: 210 mm
- Height: 44 mm
- Weight: 2.72 kg
Packaging content
- Quick start guide: Yes
Certificates
- Certification: CE, FCC, RCM, VCCI, IC, BSMI, cUL, BSMI, CB
