Name: Zyxel RGS200-12P Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Brand: ZYXEL
Price: 939.8 USD
Availability: InStock

Zyxel RGS200-12P Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

$939.80

$939.80 without VAT

Zyxel RGS200-12P Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black. More info

Amount

Brand: ZYXEL

SKU: 77637 PRC: 139938 EAN: 4718937592050 PN: RGS200-12P-ZZ0101F

Description

Specifications

Management features

Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Web-based management: Yes
ARP inspection: Yes
System event log: Yes
MIB support: RFC 2233 IF MIB, RFC1213 MIB II, RFC 1757 RMON 1/2/3/9, RFC1215, RFC1493, RFC 2674, LLDP-EXT-MED MIB

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 4
Fiber optic connector: SFP

Network

Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.
10G support: No
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring: Yes
Full duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Auto-negotiation: Yes
VLAN support: Yes
Virtual LAN features: Tagged VLAN
Number of VLANs: 1024

Optical fiber

Fiber ethernet cabling technology: 1000BASE-X
Transmission distance (max): 40 km

Data transmission

Switching capacity: 24 Gbit/s
Throughput: 17.86 Mpps
MAC address table: 8000 entries
Store-and-forward: Yes
Number of queues: 8
Jumbo frames support: Yes
Jumbo frames: 9000
Packet buffer memory: 0.5 MB

Security

Access Control List (ACL): Yes
IGMP snooping: Yes
Security algorithms: 802.1x RADIUS, HTTPS, SNMP, SSH-2
MAC address filtering: Yes
SSH/SSL support: Yes
Authentication: Guest VLAN, MAC-based authentication, Port-based authentication

Multicast features

Multicast support: Yes

Design

Rack mounting: Yes
Product colour: Black
Housing material: Metal
International Protection (IP) code: IP30
Wall mountable: Yes
DIN rail mounting: Yes

Performance

Firmware upgradeable: Yes
Buffer size: 512 KB
Plug and Play: Yes
Mean time between failures (MTBF): 568430 h

Power

DC input voltage: 12 - 58 V
Input voltage: 12 - 58 V
Power consumption (max): 255 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 8
Total Power over Ethernet (PoE) budget: 240 W

Operational conditions

Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 90%
Heat dissipation: 86955 BTU/h

Weight & dimensions

Width: 77 mm
Depth: 127.3 mm
Height: 154 mm
Weight: 1.45 kg

Packaging content

Rack mount kit: Yes

Packaging data

Wall mounting kit: Yes
Package width: 133 mm
Package depth: 192 mm
Package height: 238 mm
Package weight: 1.9 kg

Logistics data

Harmonized System (HS) code: 85176990
