Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 10
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP+ module slots quantity: 2
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 80
- 10G support: No
- Full duplex: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
- Virtual LAN features: MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
- Number of VLANs: 4093
Data transmission
- Switching capacity: 60 Gbit/s
- Throughput: 44.64 Mpps
- MAC address table: 16000 entries
- Store-and-forward: Yes
- Latency (1 Gbps): 1.837 µs
- Number of queues: 8
- Jumbo frames support: Yes
- Jumbo frames: 12000
- Packet buffer memory: 16 MB
Security
- DHCP features: DHCP Option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- SSH/SSL support: Yes
- Loop protection: Yes
- BPDU filtering/protection: Yes
- Authentication: MAC-based authentication
- Authentication type: RADIUS
Multicast features
- Multicast support: Yes
- IPv4 multicast entries: 2000
- IPv6 multicast entries: 2000
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: PoE, Power, Status
Performance
- Built-in processor: Yes
- Processor model: ARM Cortex-A9
- Processor frequency: 1250 MHz
- Internal memory: 2048 MB
- Noise level: 66.23 dB
- Mean time between failures (MTBF): 947871 h
Power
- Power consumption (typical): 837.7 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 720 W
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 90%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 3000 m
- Non-operating altitude: 0 - 3000 m
- Heat dissipation: 2859.91 BTU/h
Weight & dimensions
- Width: 440 mm
- Depth: 200 mm
- Height: 43.2 mm
- Weight: 3.83 kg
Logistics data
- Harmonized System (HS) code: 85176990
