Description
The UNYKAch FLEX 1U standard 250W is a compact form factor power supply unit weighing 990 g, in silver, with dimensions of 100 x 40 x 195 mm (width x height x depth), designed for low-profile builds. It delivers a total power of 250 W with an AC input voltage of 100 - 230 V and an input frequency of 50 - 60 Hz, and features active power factor correction (PFC). It distributes the load with 18 A on the +12 V1 rail, 10 A on +12 V2, 16 A on +3.3V, 2 A on +5Vsb and 0.5 A on -12V. It protects the equipment against overcurrent, overvoltage, short circuit and undervoltage. In terms of connections, it includes a 20+4 pin ATX motherboard power connector, a 4+4 pin EPS connector, two 4-pin Molex peripheral connectors and a floppy drive connector, with cable lengths ranging from 40 cm for the motherboard to 89 cm for the floppy drive, including 400, 560 and 700 mm for SATA and 710 and 560 mm for Molex.
Specifications
Power
- Total power: 250 W
- AC input voltage: 100 - 230 V
- AC input frequency: 50 - 60 Hz
- Power Factor Correction (PFC) type: Active
- Max output current (+3.3V): 16 A
- Max output current (+12V1): 18 A
- Max output current (+12V2): 10 A
- Max output current (-12V): 0.5 A
- Max output current (+5Vsb): 2 A
- Power protection features: Over current, Over voltage, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector: 20+4 pin ATX
- Motherboard power cable length: 40 cm
- SATA power cable length: 400, 560, 700 mm
- Peripheral (Molex) power connectors (4-pin): 2
- Peripheral (Molex) power cable length: 710, 560 mm
- EPS power connector (4+4 pin): Yes
- Floppy disk drive connector: Yes
- Floppy disk drive cable length: 89 cm
Performance
- Purpose: Server
- Power supply unit (PSU) form factor: Flex ATX
- ATX version: 2.3
Design
- Product colour: Silver
- Fan diameter: 4 cm
- Number of fans: 1 fan(s)
- Fan speed: 0 - 1000 RPM
- Fan location: Rear
Certificates
- Compliance certificates: RoHS
- Certification: CE
Weight & dimensions
- Width: 100 mm
- Depth: 195 mm
- Height: 40 mm
- Weight: 990 g
Packaging data
- Package width: 100 mm
- Package depth: 195 mm
- Package height: 40 mm
- Package weight: 990 g
