UNYKAch ATX 500W power supply unit 20+4 pin ATX Silver

$15.24
$15.24 without VAT

UNYKAch ATX 500W power supply unit 20+4 pin ATX Silver.   More info

Brand: UNYKACH
SKU: 82501 PRC: 256607 EAN: 6940533542759 PN: 52099

Description

Specifications

Power

  • Total power: 500 W
  • AC input voltage: 230 V
  • AC input frequency: 50 - 60 Hz
  • Max output current (+3.3V): 28 A
  • Max output current (+12V1): 22 A
  • Max output current (+5V): 28 A
  • Max output current (-12V): 0.5 A
  • Max output current (+5Vsb): 2 A
  • Efficiency: 78%
  • Power protection features: Over current, Over power, Over voltage, Overheating, Overload, Short circuit, Under voltage

Ports & interfaces

  • Floppy disk drive connector: Yes
  • Floppy disk drive cable length: 62 cm
  • Cabling type: Non-Modular
  • Motherboard power connector: 20+4 pin ATX
  • Motherboard power cable length: 31 cm
  • Number of SATA power connectors: 3
  • SATA power cable length: 300, 480 mm
  • Peripheral (Molex) power connectors (4-pin): 2
  • Peripheral (Molex) power cable length: 480, 620 mm
  • Floppy drive power connector: 1

Performance

  • Supported motherboard form factors: ATX
  • Purpose: PC/Server
  • Power supply unit (PSU) form factor: ATX
  • ATX version: 2.03
  • Noise level: 28 dB

Design

  • Product colour: Silver
  • Fan diameter: 12 cm
  • Number of fans: 1 fan(s)
  • On/off switch: Yes

Certificates

  • Compliance certificates: RoHS
  • Certification: EN60950, TÜV

Weight & dimensions

  • Width: 150 mm
  • Depth: 140 mm
  • Height: 85 mm
  • Weight: 747 g

Packaging data

  • Package width: 165 mm
  • Package depth: 215 mm
  • Package height: 90 mm
  • Package weight: 879 g

Logistics data

  • Products per pallet: 10 pc(s)
