Description
The managed L2 TP-Link TL-RP108GE switch in black features eight Gigabit Ethernet RJ-45 ports (10/100/1000) with PoE support to power compatible network devices. It offers advanced management with QoS, support for 4000 VLANs (port-based or tagged), port mirroring and storm control to optimise traffic. Its switching capacity reaches 16 Gbit/s and it supports jumbo frames of up to 16000 bytes, while its half-duplex and full-duplex operation conforms to the IEEE 802.3ab, 802.3i, 802.3p, 802.3q, 802.3u and 802.3x standards. Configuring this equipment allows you to limit the transmission rate and manage the network according to your needs.
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3p, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Port mirroring: Yes
- Full duplex: Yes
- Half duplex: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- VLAN support: Yes
- Virtual LAN features: Port-based VLAN, Tagged VLAN
- Number of VLANs: 4000
Data transmission
- Switching capacity: 16 Gbit/s
- Forwarding rate: 11.9 Mpps
- MAC address table: 4000 entries
- Store-and-forward: Yes
- Static route: Yes
- Jumbo frames support: Yes
- Jumbo frames: 16000
Security
- IGMP snooping: Yes
- Loop protection: Yes
Design
- Product colour: Black
- Reset button: Yes
- LED indicators: Yes
Power
- Power source: DC
- Power supply included: No
- Input current: 1 A
- Input voltage: 5 V
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) type supported: Passive PoE
- Power over Ethernet (PoE) ports quantity: 8
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 158 mm
- Depth: 99.1 mm
- Height: 25 mm
Certificates
- Certification: FCC, CE, RoHS
Logistics data
- Harmonized System (HS) code: 85176990
