Name: TP-Link Omada 28-Port Gigabit Smart Switch with 24-Port PoE+
Brand: TP-LINK
Price: 288.51 USD
Availability: InStock

TP-Link Omada 28-Port Gigabit Smart Switch with 24-Port PoE+

$288.51

$288.51 without VAT

Amount

Brand: TP-LINK

SKU: 84914 PRC: 291118 EAN: 6935364030650 PN: TL-SG2428P

Description

TP-Link Omada 28-Port Gigabit Smart Switch with 24-Port PoE+, Managed, L2/L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U

Specifications

Management features

Switch type: Managed
Switch layer: L2/L2+
Quality of Service (QoS) support: Yes
Web-based management: Yes
ARP inspection: Yes
System event log: Yes
MIB support: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 24
SFP module slots quantity: 4

Network

Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802
10G support: No
Copper ethernet cabling technology: 10BASE-T, 1000BASE-T
Cable types supported: Cat3, Cat4, Cat5, Cat5e
Port mirroring: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
VLAN support: Yes
Virtual LAN features: MAC address-based VLAN, Protocol-based VLAN, Voice VLAN
Number of VLANs: 4000

Optical fiber

Fiber ethernet cabling technology: 1000BASE-X

Data transmission

Switching capacity: 56 Gbit/s
Forwarding rate: 41.66 Mpps
MAC address table: 8000 entries
Number of queues: 8
Jumbo frames support: Yes
Jumbo frames: 9000
Packet buffer memory: 4.1 MB

Security

DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client
Access Control List (ACL): Yes
IGMP snooping: Yes
Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2, SSL/TLS
SSH/SSL support: Yes
BPDU filtering/protection: Yes
IP-MAC-Port binding: Yes
Authentication type: RADIUS
Queue scheduling algorithms: SP, WRR+SP, Weighted Round Robin (WRR)

Multicast features

Multicast support: Yes

Protocols

Management protocols: SNMPv1/v2c/v3, SNTP

Design

Rack mounting: Yes
Form factor: 1U
Product colour: Black
Number of fans: 2 fan(s)

Performance

Firmware upgradeable: Yes

Power

Power source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 301.1 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 250 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Heat dissipation: 1052.94 BTU/h

Weight & dimensions

Width: 440 mm
Depth: 220 mm
Height: 44 mm

Packaging content

Cables included: AC
User guide: Yes
Rack mount kit: Yes

Certificates

Certification: CE, FCC, RoHS
