TP-Link 16-Port Gigabit Rackmount Network Switch

$59.04
$59.04 without VAT

More info

Brand: TP-LINK
SKU: 71299 PRC: 6022 EAN: 5052217234896 PN: TL-SG1016

Description

TP-Link 16-Port Gigabit Rackmount Network Switch, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting, 1U

Specifications

Management features

  • Switch type: Unmanaged
  • Quality of Service (QoS) support: Yes

Ports & interfaces

  • Basic switching RJ-45 Ethernet ports quantity: 16
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Gigabit Ethernet (copper) ports quantity: 16
  • Power connector: AC-in jack

Network

  • Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • 10G support: No
  • Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
  • Cable types supported: Cat3, Cat4, Cat5, Cat5e
  • Full duplex: Yes
  • Half duplex: Yes
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes

Data transmission

  • Switching capacity: 32 Gbit/s
  • Forwarding rate: 23.8 Mpps
  • MAC address table: 8000 entries
  • Store-and-forward: Yes
  • Jumbo frames support: Yes
  • Jumbo frames: 10000

Design

  • Rack mounting: Yes
  • Form factor: 1U
  • Product colour: Black
  • Housing material: Metal
  • LED indicators: Yes

Performance

  • Compatible operating systems: Microsoft Windows 2000/XP/2003/Vista/2008/7/2012/8/10 MacOS NetWare UNIX Linux
  • Maximum cable length: 100 m
  • Fanless: Yes

Power

  • Power source: AC
  • Power supply included: Yes
  • AC input voltage: 100 - 240 V
  • AC input frequency: 50/60 Hz
  • Power consumption (max): 10.44 W

Power over Ethernet (PoE)

  • Power over Ethernet (PoE): No

Operational conditions

  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%
  • Heat dissipation: 35.6 BTU/h

Weight & dimensions

  • Width: 440 mm
  • Depth: 180 mm
  • Height: 44 mm

Packaging content

  • Cables included: AC
  • User guide: Yes
  • Rack mount kit: Yes

Packaging data

  • Package type: Box
  • Package width: 250 mm
  • Package depth: 528 mm
  • Package height: 80 mm
  • Package weight: 2.04 kg

Sustainability

  • Sustainability compliance: Yes

Certificates

  • Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Logistics data

  • Harmonized System (HS) code: 85176990
