Description
The TP-Link LiteWave LS108GP switch, in its black version, is an unmanaged device with 8 Gigabit Ethernet ports (10/100/1000) that incorporates PoE power supply to simplify the deployment of network devices. It supports Quality of Service (QoS) and flow control, as well as offering auto-negotiation and auto MDI/MDI-X on each connection. With a switching capacity of 16 Gbit/s, a MAC address table of 4000 entries, and support for jumbo frames of 16000 bytes, this model manages traffic efficiently. Its maximum power consumption is 71.61 W and it includes LED indicators to monitor the network status, complying with standards such as IEEE 802.3af and 802.3at.
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Power connector: DC-in jack
Network
- Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support: No
- Cable types supported: Cat3, Cat4, Cat5, Cat5e
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
Data transmission
- Switching capacity: 16 Gbit/s
- Forwarding rate: 11.9 Mpps
- MAC address table: 4000 entries
- Jumbo frames: 16000
Design
- Product colour: Black
- LED indicators: Yes
Power
- Power source: DC/PoE
- Power supply included: Yes
- AC input voltage: 220 V
- AC input frequency: 50 Hz
- DC input voltage: 53.5 V
- Input current: 1.31 A
- Power consumption (max): 71.61 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 8
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 62 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 243.47 BTU/h
Weight & dimensions
- Width: 158 mm
- Depth: 99 mm
- Height: 25 mm
Packaging content
- User guide: Yes
Packaging data
- Package type: Box
Certificates
- Certification: CE, FCC, RoHS
