LevelOne KILBY 10-Port L2 Managed Gigabit Switch, 2 x SFP

Few units

Product 1 image

Product 2 image

Product 3 image

Product 4 image

LevelOne KILBY 10-Port L2 Managed Gigabit Switch, 2 x SFP

86.44 €

71.44 € without VAT

Amount

Brand: LEVELONE

SKU: 78807 PRC: 155395 EAN: 4015867197202 PN: 55120103

Description

LevelOne KILBY 10-Port L2 Managed Gigabit Switch, 2 x SFP, Managed, L2, Gigabit Ethernet (10/100/1000), Rack mounting

Specifications

Management features

Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Traffic classification: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Fiber optic connector: SFP
Console port: RJ-45
Power connector: AC-in jack

Network

Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.
10G support: No
Port mirroring: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
Cable length detection: Yes
VLAN support: Yes
Virtual LAN features: Port-based VLAN, Tagged VLAN

Optical fiber

Fiber ethernet cabling technology: 100BASE-X, 1000BASE-X

Data transmission

Switching capacity: 20 Gbit/s
Throughput: 14.9 Mpps
MAC address table: 8000 entries
Number of queues: 8
Jumbo frames support: Yes
Jumbo frames: 9000
Packet buffer memory: 1 MB

Security

Access Control List (ACL): Yes
IGMP snooping: Yes
MAC address filtering: Yes
Static port security: Yes

Design

Rack mounting: Yes
Product colour: Black
Reset button: Yes
LED indicators: Activity, Link, Power

Performance

Internal memory: 128 MB
Flash memory: 16 MB
Fanless: No
Minimum system requirements: CE RoHS

Power

Power source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 15 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): No

Operational conditions

Operating temperature (T-T): -10 - 50 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 270 mm
Depth: 181 mm
Height: 44 mm
Weight: 800 g

Packaging content

Cables included: AC
Quick start guide: Yes

Packaging data

Package type: Box
Package width: 345 mm
Package depth: 255 mm
Package height: 82 mm
Package weight: 2 kg

Logistics data

Harmonized System (HS) code: 85176990
