Description
LevelOne Hilbert 10-Port Gigabit PoE Smart Lite Switch, 8 PoE Outputs, 2 x Gigabit SFP, 802.3at/af PoE, 130W PoE Power Budget, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE)
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 8
- SFP module slots quantity: 2
Network
- Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
- VLAN support: Yes
- Virtual LAN features: Tagged VLAN
- Number of VLANs: 32
Data transmission
- Switching capacity: 20 Gbit/s
- MAC address table: 8000 entries
- Number of queues: 4
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Packet buffer memory: 4.1 MB
Security
- IGMP snooping: Yes
Multicast features
- Multicast support: Yes
Design
- Rack mounting: No
- Product colour: Black
- LED indicators: Activity, Link, PoE
Performance
- Flash memory: 2 MB
- Noise level: 0 dB
- Fanless: Yes
- Mean time between failures (MTBF): 43800 h
Power
- Power source: AC/PoE
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 150 W
- Surge protection: Yes
- Surge protection voltage: 8 kV
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 8
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 130 W
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 95%
- Heat dissipation: 40.94 BTU/h
Weight & dimensions
- Width: 271 mm
- Depth: 181.5 mm
- Height: 44.5 mm
- Weight: 1.2 kg
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Packaging data
- Package type: Box
- Package width: 350 mm
- Package depth: 267 mm
- Package height: 89 mm
- Package weight: 1.75 kg
Sustainability
- Sustainability compliance: Yes
Technical details
- Master (outer) cases per pallet (air): 12 pc(s)
- Pallet gross length: 80 cm
- Pallet gross width: 120 cm
- Pallet height (air): 182.4 cm
Certificates
- Compliance certificates: CE, RoHS
- Certification: UKCA, FCC Class A
Logistics data
- Master (outer) case net weight: 1 kg
- Country of origin: China
- Master (outer) case width: 480 mm
- Master (outer) case length: 370 mm
- Master (outer) case height: 560 mm
- Master (outer) case gross weight: 18.5 kg
- Products per master (outer) case: 10 pc(s)
