Description
Specifications
Management features
- Switch type: Managed
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- System event log: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 9
- Fiber ports quantity: 1
- Fiber optic connector: SFP
- Power connector: AC-in jack
Network
- Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 80
- 10G support: Yes
- Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Broadcast storm control: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
Optical fiber
- Fiber ethernet cabling technology: 1000Base-X
- Switching optical modules type: Gigabit Ethernet
Data transmission
- Switching capacity: 20 Gbit/s
- Forwarding rate: 14.88 Mpps
- MAC address table: 4000 entries
- Jumbo frames support: Yes
- Jumbo frames: 9216
- Packet forwarding rate (1 Gbps): 1488000 pps
- Packet forwarding rate (100 Mbps): 148800 pps
- Packet forwarding rate (10 Mbps): 14880 pps
- Packet buffer memory: 1.5 MB
Security
- IGMP snooping: Yes
Multicast features
- Multicast support: Yes
- Number of multicast groups filtered: 128
Design
- Rack mounting: Yes
- Stackable: No
- Product colour: Black
- Housing material: Metal
- Reset button: Yes
- LED indicators: Activity, Link, PoE, Power, Status
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 8
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 100 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 265 mm
- Depth: 184 mm
- Height: 44 mm
- Weight: 1.62 kg
Packaging content
- Rack mount kit: Yes
Certificates
- Certification: FCC, CE, BSMI
