Description
The Edimax GS-1016 V2 switch in black is a managed model with 16 RJ-45 Gigabit Ethernet ports (10/100/1000), designed for networks requiring advanced control and configuration. It offers support for QoS, flow control, auto-negotiation, Auto MDI/MDI-X and full duplex mode, as well as compatibility with standards such as IEEE 802.3, 802.3ab, 802.3az and 802.3x. Its MAC address table reaches 8000 entries, supports jumbo frames of up to 10000 bytes and achieves a switching capacity of 32 Gbit/s, with forwarding rates of 1,488,000 pps at 1 Gbps. It includes three speed models (10, 100 and 1000 Mbit/s) and cabling technology 10BASE-T, 100BASE-T and 1000BASE-T, making it suitable for demanding office or home environments.
Specifications
Management features
- Switch type: Managed
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 16
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x
- Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
- Full duplex: Yes
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Auto-negotiation: Yes
Data transmission
- Switching capacity: 32 Gbit/s
- Throughput: 1 Gbit/s
- MAC address table: 8000 entries
- Jumbo frames support: Yes
- Jumbo frames: 10000
- Transmission method: Store and forward
- Packet forwarding rate (1 Gbps): 1488000 pps
- Packet forwarding rate (100 Mbps): 148800 pps
- Packet forwarding rate (10 Mbps): 14880 pps
- Packet buffer memory: 4.1 MB
Design
- Rack mounting: Yes
- Product colour: Black
- Housing material: Metal
- LED indicators: Activity, Link, Power
- Wall mountable: Yes
Performance
- Fanless: Yes
Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 215 mm
- Depth: 133 mm
- Height: 42 mm
- Weight: 850 g
Packaging content
- Rack mount kit: Yes
Logistics data
- Harmonized System (HS) code: 85176990
