Description
The managed Edimax GS-5654PLX switch integrates 48 RJ-45 Gigabit Ethernet (10/100/1000) ports with PoE support and 6 SFP+ slots, all in a black desktop chassis. It offers web-based management with event logging and Quality of Service (QoS) functions, plus per-port VLAN policies and Voice VLAN. Its switching capacity reaches 216 Gbit/s, with support for jumbo frames up to 12000 bytes and packet forwarding rates of 14880000 pps at 1 Gbps, 14880 pps at 10 Mbps and 14800 pps at 100 Mbps. It includes rate limiting and port mirroring for detailed traffic control, with 10G compatibility for high-demand links.
Specifications
Management features
- Switch type: Managed
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- System event log: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP+ module slots quantity: 6
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3
- 10G support: Yes
- Port mirroring: Yes
- Rate limiting: Yes
- VLAN support: Yes
- Virtual LAN features: Port-based VLAN, Voice VLAN
Data transmission
- Switching capacity: 216 Gbit/s
- Throughput: 160.7 Mpps
- Forwarding rate: 160.7 Mpps
- MAC address table: 32000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 12000
- Packet forwarding rate (1 Gbps): 14880000 pps
- Packet forwarding rate (100 Mbps): 14800 pps
- Packet forwarding rate (10 Mbps): 14880 pps
Security
- DHCP features: DHCP snooping
- IGMP snooping: Yes
- Queue scheduling algorithms: SP, WRR+SP, Weighted Round Robin (WRR)
Design
- Rack mounting: Yes
- Product colour: Black
- Reset button: Yes
- LED indicators: Link, System
- Number of fans: 1 fan(s)
Performance
- Firmware upgradeable: Yes
Power
- Power source: AC
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Total Power over Ethernet (PoE) budget: 400 W
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 441 mm
- Depth: 330 mm
- Height: 45 mm
- Weight: 5.6 kg
Logistics data
- Harmonized System (HS) code: 85176990
