Description
The D-Link GO-SW-5G switch is an unmanaged white device that expands your local network with five Gigabit Ethernet RJ-45 ports (10/100/1000). Thanks to its full duplex and Auto MDI/MDI-X support, each port automatically negotiates the speed and cable type. It incorporates QoS to prioritise sensitive traffic and store and forward to forward only valid frames, with jumbo frames of up to 9216 bytes. It reaches a switching capacity of 10 Gbit/s and forwarding rates of 1488000 pps at 1 Gbps, 148800 pps at 100 Mbps and 14880 pps at 10 Mbps. Its MAC address table supports 2000 entries and the packet buffer memory is 0.128 MB, complying with the IEEE 802.3, 802.3ab, 802.3az, 802.3u and 802.3x standards. The LED indicators show the connection status. Weighing 75 g and measuring 94 x 22.4 x 75 mm (width x height x depth), it is easily placed on any surface.
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 5
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Full duplex: Yes
- Auto MDI/MDI-X: Yes
Data transmission
- Switching capacity: 10 Gbit/s
- MAC address table: 2000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9216
- Packet forwarding rate (1 Gbps): 1488000 pps
- Packet forwarding rate (100 Mbps): 148800 pps
- Packet forwarding rate (10 Mbps): 14880 pps
- Packet buffer memory: 0.128 MB
Design
- Rack mounting: No
- Product colour: White
- LED indicators: Yes
Power
- Power source: DC
- DC input voltage: 5 V
- Input current: 1 A
- Power consumption (max): 2.87 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -10 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 94 mm
- Depth: 75 mm
- Height: 22.4 mm
- Weight: 75 g
Packaging content
- Manual: Yes
Certificates
- Certification: CE class B, FCC class B, ICES-003 class B, VCCI class B, BSMI, LVD, RCM, Anatel, KCC
Logistics data
- Harmonized System (HS) code: 85176990
