Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- ARP inspection: Yes
- Configuring Location Settings (CLI): Yes
- System event log: Yes
- MIB support: RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RF
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP+ module slots quantity: 4
- Console port: RJ-45
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.
- 10G support: Yes
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Cable types supported: Cat5, Cat5e
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Auto MDI/MDI-X: Yes
- Spanning tree protocol: Yes
- Head-of-line (HOL) blocking: Yes
- VLAN support: Yes
- Virtual LAN features: Voice VLAN
- Number of VLANs: 4094
Optical fiber
- Fiber ethernet cabling technology: 100BASE-FX, 1000BASE-LHX, 1000BASE-X, 1000BASE‑LX, 1000BASE‑SX, 1000BASE‑ZX
Data transmission
- Switching capacity: 128 Gbit/s
- Forwarding rate: 95.24 Mpps
- MAC address table: 16000 entries
- Store-and-forward: Yes
- Static route: Yes
- Number of static routes: 124
- Jumbo frames support: Yes
- Jumbo frames: 12000
- Packet buffer memory: 12 MB
Security
- DHCP features: DHCP client, DHCP server, DHCP snooping
- Access Control List (ACL): Yes
- Access Control List (ACL) rules: 768
- IGMP snooping: Yes
- Security algorithms: EAP, MD5, PEAP, SSH, SSL/TLS, TTLS
- Loop protection: Yes
- IP-MAC-Port binding: Yes
- Queue scheduling algorithms: Weighted Round Robin (WRR)
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Product colour: Black
- LED indicators: Activity, Link, Power, Speed
- Electromagnetic compatibility: CE A, VCCI A, FCC A, IC, BSMI
Performance
- Memory type: DDR3-SDRAM
- Internal memory: 2048 MB
- Flash memory: 64 MB
- Noise level: 47.6 dB
- Firmware upgradeable: Yes
- Mean time between failures (MTBF): 743482.45 h
Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 30.6 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Heat dissipation: 104.346 BTU/h
Weight & dimensions
- Width: 440 mm
- Depth: 140 mm
- Height: 44 mm
- Weight: 3.86 kg
Packaging data
- Package width: 282 mm
- Package depth: 563 mm
- Package height: 89 mm
- Package weight: 2.97 kg
Technical details
- Shipping (inner) case height: 31.8 cm
- Shipping (inner) case width: 47.8 cm
- Shipping (inner) case length: 58.5 cm
- Shipping (inner) case net weight: 11.6 kg
- Products per shipping (inner) case: 5 pc(s)
- Pallet gross weight (air): 407.6 kg
- Master (outer) cases per pallet (air): 24 pc(s)
- Products per pallet (air): 120 pc(s)
- Pallet gross length: 110 cm
- Pallet gross width: 120 cm
- Pallet height (air): 2.04 m
- Pallet gross weight (sea): 407.6 kg
- Master (outer) cases per pallet (sea): 24 pc(s)
- Products per pallet (sea): 120 pc(s)
- Pallet height (sea): 2.04 m
- Shipping (inner) case gross weight: 16.2 kg
Certificates
- Certification: CB, UL, BSMI, CCC
Logistics data
- Harmonized System (HS) code: 85176990
