Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Cloud-managed: No
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP+ module slots quantity: 4
- Power connector: DC-in jack
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x
- 10G support: Yes
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Auto MDI/MDI-X: Yes
- Head-of-line (HOL) blocking: Yes
- VLAN support: Yes
Data transmission
- Switching capacity: 176 Gbit/s
- Throughput: 130.95 Mpps
- MAC address table: 16000 entries
- Store-and-forward: Yes
- Packet buffer memory: 3 MB
Security
- DHCP features: DHCP server, DHCP client
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- MAC address filtering: Yes
- SSH/SSL support: Yes
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: Activity, Link, Power
- Number of fans: 2 fan(s)
- Safety: cUL, CB
Performance
- Noise level: 45.8 dB
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 44.2 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Heat dissipation: 138.8 BTU/h
Weight & dimensions
- Width: 440 mm
- Depth: 250 mm
- Height: 44 mm
- Weight: 5.3 kg
Packaging data
- Package width: 365 mm
- Package depth: 555 mm
- Package height: 101 mm
- Package weight: 4.62 kg
Technical details
- Shipping (inner) case height: 39.8 cm
- Shipping (inner) case width: 32.4 cm
- Shipping (inner) case length: 57.3 cm
- Shipping (inner) case net weight: 11.4 kg
- Products per shipping (inner) case: 3 pc(s)
- Pallet gross weight (air): 375.1 kg
- Master (outer) cases per pallet (air): 24 pc(s)
- Products per pallet (air): 72 pc(s)
- Pallet gross length: 110 cm
- Pallet gross width: 120 cm
- Pallet height (air): 173 cm
- Pallet gross weight (sea): 375.1 kg
- Master (outer) cases per pallet (sea): 24 pc(s)
- Products per pallet (sea): 72 pc(s)
- Pallet height (sea): 173 cm
- Shipping (inner) case gross weight: 14.9 kg
Certificates
- Certification: CE, FCC, C-Tick, VCCI, BSMI, CCC
Logistics data
- Harmonized System (HS) code: 85176990
