Name: TP-Link Omada AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point
Brand: TP-LINK
Price: 84.74 USD
Availability: InStock

TP-Link Omada AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point

$84.74

$84.74 without VAT

Amount

Brand: TP-LINK

SKU: 77789 PRC: 141810 EAN: 6935364096663 PN: EAP245

Description

TP-Link Omada AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point, 2.4 GHz, 5 GHz, 1750 Mbit/s, 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 10,100,1000 Mbit/s

Specifications

Features

2.4 GHz: Yes
5 GHz: Yes
6 GHz: No
Maximum data transfer rate: 1750 Mbit/s
Maximum data transfer rate (2.4 GHz): 450 Mbit/s
Maximum data transfer rate (5 GHz): 1300 Mbit/s
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Frequency band: 2.4 - 5 GHz
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Cabling technology: 10/100/1000Base-T(X)
Automatic channel selection: Yes
Automatic channel scanning: Yes
MIMO: Yes
MIMO type: Multi User MIMO
Wi-Fi Multimedia (WMM)/(WME): Yes
VLAN support: Yes
Virtual LAN features: SSID-based VLAN assignment
Rate limiting: Yes
Wireless isolation: Yes
Band steering: Yes
Airtime Fairness (ATF): Yes
Quality of Service (QoS) support: Yes
BeamForming: Yes
Transmitting power (CE): 20 - 23 dBm
Transmitting power (FCC): 24 dBm
Transmitting power: 27 dBmW

Security

Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
MAC address filtering: Yes
Service Set Identifier (SSID) features: Multiple SSIDs
Number of SSID supported: 16
Port-based Network Access Control (PNAC): Yes
Access Control List (ACL): Yes

Protocols

Management protocols: HTTP/HTTPS

Management features

Web-based management: Yes
Syslog: Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2

Power

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: Active PoE, Passive PoE
Output voltage: 12 V
Output current: 1.5 A
Power consumption (typical): 12.7 W

Design

Placement: Ceiling, Wall
Product colour: White
Cable lock slot: Yes
Cable lock slot type: Kensington
Reset button: Yes
LED indicators: Power

Antenna

Antenna type: Internal
Antenna direction type: Omni-directional
Antenna features: Integrated antenna
Antenna gain level (max): 4 dBi

Performance

Compatible operating systems: Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Weight & dimensions

Width: 180 mm
Depth: 180 mm
Height: 47.5 mm

Packaging data

Package width: 228 mm
Package depth: 340 mm
Package height: 65 mm
Package weight: 1.18 kg

Packaging content

Quantity per pack: 1 pc(s)
PoE adapter included: Yes
Cables included: AC
Mounting kit: Yes
Quick start guide: Yes

Operational conditions

Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%

Sustainability

Sustainability compliance: Yes

Logistics data

Harmonized System (HS) code: 85176990
