TP-Link Omada AX3000 Wall Plate WiFi 6 Access Point

$116.17
$116.17 without VAT

TP-Link Omada AX3000 Wall Plate WiFi 6 Access Point.   More info

Brand: TP-LINK
SKU: 96514 PRC: 396542 EAN: 4897098682111 PN: EAP655-WALL

Description

Specifications

Features

  • 2.4 GHz: Yes
  • 5 GHz: Yes
  • 6 GHz: No
  • Maximum data transfer rate: 2402 Mbit/s
  • Maximum data transfer rate (2.4 GHz): 574 Mbit/s
  • Maximum data transfer rate (5 GHz): 2402 Mbit/s
  • Ethernet LAN data rates: 10, 100, 1000 Mbit/s
  • Frequency band: 2.4, 5 GHz
  • Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
  • Cabling technology: 10/100/1000Base-T(X)
  • Number of users: 100 user(s)
  • Automatic channel selection: Yes
  • Wi-Fi Multimedia (WMM)/(WME): Yes
  • VLAN support: Yes
  • Rate limiting: Yes
  • Wireless isolation: Yes
  • Band steering: Yes
  • Airtime Fairness (ATF): Yes
  • Quality of Service (QoS) support: Yes
  • BeamForming: Yes
  • Transmitting power (CE): 20 - 23 - 26 dBm
  • Transmitting power (FCC): 21 - 21 dBm

Security

  • Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise
  • MAC address filtering: Yes
  • IP address filtering: Yes
  • Service Set Identifier (SSID) features: Multiple SSIDs
  • Number of SSID supported: 16
  • Remote Authentication Dial-In User Service (RADIUS): Yes
  • Access Control List (ACL): Yes

Management features

  • Web-based management: Yes
  • Syslog: Yes
  • Firmware upgradeable: Yes

Ports & interfaces

  • Ethernet LAN (RJ-45) ports: 4
  • WAN connection: Ethernet (RJ-45)
  • DC-in jack: Yes

Power

  • Power over Ethernet (PoE): Yes
  • Power consumption (typical): 12 W

Design

  • Placement: Wall
  • Product colour: White
  • Cable lock slot: No
  • Reset button: Yes
  • LED indicators: Yes

Antenna

  • Antenna type: Internal
  • Antennas quantity: 2
  • Antenna gain level (max): 5 dBi

Performance

  • Compatible operating systems: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux

Certificates

  • Compliance certificates: RoHS
  • Certification: FCC, RoHS

Weight & dimensions

  • Width: 143 mm
  • Depth: 86 mm
  • Height: 42.6 mm

Packaging data

  • Package width: 117 mm
  • Package depth: 184 mm
  • Package height: 56 mm
  • Package weight: 400 g
  • Package type: Box

Packaging content

  • Quantity per pack: 1 pc(s)
  • Mounting kit: Yes

Operational conditions

  • Operating relative humidity (H-H): 10 - 90%
  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Storage relative humidity (H-H): 5 - 90%
