Name: TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point
Brand: TP-LINK
Price: 79.98 USD
Availability: InStock

TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point

$79.98

$79.98 without VAT

TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point. More info

Amount

Brand: TP-LINK

SKU: 97423 PRC: 415350 EAN: 4895252500516 PN: EAP613

Description

Specifications

Features

Frequency band: 2.4 - 5 GHz
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Automatic channel selection: Yes
Automatic channel scanning: Yes
MIMO: Yes
MIMO type: Multi User MIMO
Spread spectrum method: OFDMA
Wi-Fi Multimedia (WMM)/(WME): Yes
VLAN support: Yes
Rate limiting: Yes
Wireless isolation: Yes
Band steering: Yes
Airtime Fairness (ATF): Yes
BeamForming: Yes
Transmitting power (CE): <20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz band1/2, EIRP); <25 dBm (5 GHz band3)
Transmitting power (FCC): <25 dBm (2.4 GHz); <25 dBm (5 GHz)
2.4 GHz: Yes
5 GHz: Yes
6 GHz: No
Maximum data transfer rate: 1775 Mbit/s
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 1201 Mbit/s
Ethernet LAN data rates: 100, 1000 Mbit/s

Security

Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, WPA, WPA2, WPA3
Number of SSID supported: 16

Management features

Web-based management: Yes
Management platform: Omada

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes

Power

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: Passive PoE
DC voltage range: 12 V
Input current: 1 A
Power consumption (typical): 9.6 W
Power consumption (max): 10.6 W

Design

Placement: Ceiling, Wall
Product colour: White
Reset button: Yes
LED indicators: Yes

Antenna

Antenna type: Internal
Antennas quantity: 4
Antenna gain level (max): 5 dBi

Performance

Compatible operating systems: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux

Certificates

Certification: CE, FCC, RoHS

Weight & dimensions

Width: 160 mm
Depth: 160 mm
Height: 33.6 mm

Packaging content

Quantity per pack: 1 pc(s)
Mounting kit: Yes
Quick start guide: Yes

Operational conditions

Operating relative humidity (H-H): 0 - 40%
Operating temperature (T-T): 10 - 90 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
