TP-Link Omada AX5400 Ceiling Mount WiFi 6 Access Point, 2.4 GHz, 5 GHz, 5400 Mbit/s, 2500 Mbit/s

Specifications

Features


  • 2.4 GHz: Yes
  • 5 GHz: Yes
  • 6 GHz: No
  • Maximum data transfer rate: 5400 Mbit/s
  • Maximum data transfer rate (2.4 GHz): 574 Mbit/s
  • Maximum data transfer rate (5 GHz): 4804 Mbit/s
  • Ethernet LAN data rates: 2500 Mbit/s
  • Frequency band: 2.4 - 5 GHz
  • Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
  • Number of users: 250 user(s)
  • Automatic channel selection: Yes
  • Automatic channel scanning: Yes
  • MIMO: Yes
  • MIMO type: Multi User MIMO
  • VLAN support: No
  • Rate limiting: Yes
  • Wireless isolation: Yes
  • Band steering: Yes
  • Quality of Service (QoS) support: Yes
  • BeamForming: Yes
  • Transmitting power (CE): <20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz, band1 & band2, EIRP); <30 dBm(5 GHz, band3, EIRP)
  • Transmitting power (FCC): <25 dBm (2.4 GHz); <28 dBm (5 GHz)

Security


  • Service Set Identifier (SSID) features: Multiple SSIDs
  • Number of SSID supported: 16
  • Remote Authentication Dial-In User Service (RADIUS): Yes
  • Access Control List (ACL): Yes

Management features


  • Web-based management: Yes
  • Firmware upgradeable: Yes

Power


  • Power over Ethernet (PoE): Yes
  • Input current: 1.5 A

Design


  • Placement: Ceiling, Wall
  • Product colour: White
  • International Protection (IP) code: IP67
  • Reset button: Yes
  • LED indicators: Yes

Antenna


  • Antenna type: Internal
  • Antenna direction type: Omni-directional
  • Antennas quantity: 6
  • Antenna gain level (max): 5 dBi

Certificates


  • Certification: CE, FCC, RoHS

Weight & dimensions


  • Width: 243 mm
  • Depth: 243 mm
  • Height: 64 mm

Packaging data


  • Package width: 302 mm
  • Package depth: 304 mm
  • Package height: 82 mm
  • Package weight: 1.32 kg

Packaging content


  • Quantity per pack: 1 pc(s)

Logistics data


  • Harmonized System (HS) code: 85176990
