Description
TP-Link Omada 24-Port 10GBASE-T L2+ Managed Switch with 8 10GE SFP+ Slots, Managed, L2/L2+, 10G Ethernet (100/1000/10000), Rack mounting, 1U
Specifications
Management features
- Configuring Location Settings (CLI): Yes
- System event log: Yes
- Switch type: Managed
- Switch layer: L2/L2+
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Cloud-managed: Yes
- ARP inspection: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
- SFP+ module slots quantity: 8
- USB Type-C ports quantity: 1
- Console port: RJ-45/USB Type-C
Network
- Networking standards: IEEE 802.3az
- 10G support: Yes
- Port mirroring: Yes
- IP routing: Yes
- Flow control support: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Spanning tree protocol: Yes
- Ethernet LAN data rates: 10,100 Mbit/s
- VLAN support: Yes
- Virtual LAN features: MAC address-based VLAN, Multicast VLAN, Private VLAN, Voice VLAN
Data transmission
- Switching capacity: 640 Gbit/s
- Forwarding rate: 240 Mpps
- MAC address table: 32000 entries
- Static route: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Packet buffer memory: 24 MB
Security
- DHCP features: DHCP relay, DHCP server, DHCP snooping, DHCPv6 snooping
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- SSH/SSL support: Yes
- Loop protection: Yes
- Authentication: Auto VLAN, MAC-based authentication, Port-based authentication
- Authentication type: AAA, RADIUS, TACACS+
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: Yes
- Number of fans: 2 fan(s)
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Power consumption (max): 106.5 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 363.23 BTU/h
Weight & dimensions
- Width: 440 mm
- Depth: 220 mm
- Height: 44 mm
Packaging content
- Cables included: AC, LAN (RJ-45)
- Quick start guide: Yes
- Rack mount kit: Yes
