TP-Link 8-Port 10/100Mbps Desktop PoE Switch with 4-Port

$37.13
$37.13 without VAT

TP-Link 8-Port 10/100Mbps Desktop PoE Switch with 4-Port.   More info

Brand: TP-LINK
SKU: 71301 PRC: 6025 EAN: 6935364020682 PN: TL-SF1008P

Description

Specifications

Management features

  • Switch type: Unmanaged

Ports & interfaces

  • Basic switching RJ-45 Ethernet ports quantity: 8
  • Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
  • Fast Ethernet (copper) ports quantity: 8
  • Power connector: DC-in jack

Network

  • Full duplex: Yes
  • Half duplex: Yes
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes
  • MAC address auto-learning supported: Yes
  • MAC address auto-aging supported: Yes
  • Networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
  • 10G support: No
  • Copper ethernet cabling technology: 10GBASE-T, 100BASE-TX
  • Cable types supported: Cat3, Cat4, Cat5, Cat5e

Data transmission

  • Switching capacity: 1.6 Gbit/s
  • Forwarding rate: 1.1904 Mpps
  • MAC address table: 2000 entries
  • Store-and-forward: Yes

Protocols

  • IPv4 & IPv6 features: IPv6 portal

Design

  • Rack mounting: No
  • Stackable: No
  • Product colour: Black
  • Housing material: Metal
  • LED indicators: Yes
  • Wall mountable: Yes

Performance

  • Fanless: Yes

Power

  • Power source: DC/PoE
  • Power supply included: No
  • AC input voltage: 220 V
  • AC input frequency: 50 Hz
  • DC input voltage: 53.5 V
  • Input current: 1.31 A
  • Power consumption (max): 66 W

Power over Ethernet (PoE)

  • Power over Ethernet (PoE): Yes
  • Power over Ethernet plus (PoE+) ports quantity: 8
  • Total Power over Ethernet (PoE) budget: 57 W

Operational conditions

  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%
  • Heat dissipation: 248.93 BTU/h

Weight & dimensions

  • Width: 171 mm
  • Depth: 98 mm
  • Height: 27 mm

Packaging content

  • User guide: Yes

Packaging data

  • AC adapter included: Yes
  • Package type: Box
  • Package width: 223 mm
  • Package depth: 280 mm
  • Package height: 68 mm
  • Package weight: 970 g

Sustainability

  • Sustainability compliance: Yes

Certificates

  • Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Logistics data

  • Harmonized System (HS) code: 85176990
