Description
The TP-Link TL-SG1006PP unmanaged switch, in grey and with dimensions of 158 x 25 x 101 mm, provides you with six Gigabit Ethernet RJ-45 ports (10/100/1000) to set up a wired network at home or in the office. It supports Ethernet LAN with transfer speeds of 10, 100 and 1000 Mbit/s, and is compatible with Cat3, Cat4, Cat5, Cat5e and Cat6 cable types, as well as the copper cabling technologies 10BASE-T, 100BASE-TX and 1000BASE-T. As an unmanaged switch, it works without configuration, and adds auto-negotiation, Auto MDI/MDI-X and flow control. It incorporates quality of service (QoS) functions and stores and forwards frames with a forwarding rate of 8.928 Mpps and a switching capacity of 12 Gbit/s. It supports MAC address auto-learning and auto-aging, with a MAC address table of 4000 entries, and follows the IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u and IEEE 802.
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 6
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Auto-negotiation: Yes
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
Data transmission
- Switching capacity: 12 Gbit/s
- Forwarding rate: 8.928 Mpps
- MAC address table: 4000 entries
- Store-and-forward: Yes
Security
- IGMP snooping: Yes
Design
- Rack mounting: Yes
- Stackable: Yes
- Product colour: Grey
- LED indicators: Yes
Performance
- Fanless: Yes
Power
- Power source: DC/PoE
- Power supply included: Yes
- DC input voltage: 53.5 V
- Input current: 1.31 A
- Power consumption (typical): 4.75 W
- Power consumption (max): 71.46 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 4
- Total Power over Ethernet (PoE) budget: 64 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 16.2 BTU/h
Weight & dimensions
- Width: 158 mm
- Depth: 101 mm
- Height: 25 mm
Packaging content
- Quick start guide: Yes
Packaging data
- Package type: Box
Certificates
- Certification: FCC, CE, RoHS
