Description

Specifications

Ports & interfaces


  • Basic switching RJ-45 Ethernet ports quantity: 8
  • Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)

Network


  • Networking standards: IEEE 802.3af, IEEE 802.3at
  • 10G support: No

Data transmission


  • Switching capacity: 7.6 Gbit/s
  • Forwarding rate: 5.6544 Mpps
  • MAC address table: 2000 entries
  • Store-and-forward: Yes
  • Jumbo frames support: Yes
  • Jumbo frames: 16

Design


  • Rack mounting: No
  • Product colour: Black
  • Reset button: Yes
  • LED indicators: Yes

Power


  • Power source: AC/DC
  • Power supply included: Yes
  • DC input voltage: 53.5 V
  • Power consumption (max): 77.32 W

Power over Ethernet (PoE)


  • Power over Ethernet (PoE): Yes
  • Total Power over Ethernet (PoE) budget: 65 W

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%

Weight & dimensions


  • Width: 209 mm
  • Depth: 126 mm
  • Height: 26 mm

Packaging content


  • Cables included: LAN (RJ-45)

Packaging data


  • Package type: Box

Certificates


  • Certification: FCC, CE, RoHS
