Name: TP-Link 24-Port Gigabit Desktop/Rackmount Network Switch
Brand: TP-LINK
Price: 74.27 USD
Availability: InStock

TP-Link 24-Port Gigabit Desktop/Rackmount Network Switch

$74.27

$74.27 without VAT

Amount

Brand: TP-LINK

SKU: 71293 PRC: 5974 EAN: 6935364020620 PN: TL-SG1024D

Description

TP-Link 24-Port Gigabit Desktop/Rackmount Network Switch, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting

Specifications

Management features

Switch type: Unmanaged
Quality of Service (QoS) support: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 24
Power connector: DC-in jack

Network

Networking standards: IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support: No
Cable types supported: Cat3, Cat4, Cat5, Cat5e
Full duplex: Yes
Flow control support: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes

Data transmission

Supported data transfer rates: 10/100/100 Mbps
Switching capacity: 48 Gbit/s
Forwarding rate: 35.7 Mpps
MAC address table: 8000 entries
Store-and-forward: Yes
Maximum data transfer rate: 1 Gbit/s
Jumbo frames support: Yes
Jumbo frames: 10000

Protocols

Supported network protocols: CSMA/CD, TCP/IP

Design

Rack mounting: Yes
Stackable: Yes
Product colour: Grey
LED indicators: Yes

Power

Power source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 13.62 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): No

Other features

Dimensions (WxDxH): 294 x 180 x 44 mm
Connectivity technology: Wired
Bandwidth: 48 Gbit/s
Power requirements: 100 - 240V, 50/60Hz
Networking features: Gigabit Ethernet
Connectivity LEDs: Yes

Operational conditions

Operating temperature (T-T): 32 - 104 °F
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Heat dissipation: 46.44 BTU/h

Weight & dimensions

Width: 294 mm
Depth: 180 mm
Height: 44 mm

Packaging content

Cables included: AC
User guide: Yes
Rack mount kit: Yes

Packaging data

Package type: Box
Package width: 250 mm
Package depth: 400 mm
Package height: 80 mm
Package weight: 1.95 kg

Certificates

Certification: FCC, CE, RoHS

Logistics data

Harmonized System (HS) code: 85176990
