StarTech.com 8-Port PCI Express RS232 Serial Adapter Card, PCIe RS232 Serial Card, 16C1050 UART, Multiport Serial DB9 Controller/Expansion Card, 15kV ESD Protection, Windows Only - TAA

$205.67
$205.67 without VAT

StarTech.com 8-Port PCI Express RS232 Serial Adapter Card, PCIe RS232 Serial Card, 16C1050 UART, Multiport Serial DB9 Controller/Expansion Card, 15kV ESD Protection, Windows Only - TAA.   More info

Brand: STARTECH.COM
SKU: 85921 PRC: 298832 EAN: 65030888295 PN: PEX8S1050

Description

Specifications

Ports & interfaces

  • Host interface: PCIe
  • Output interface: Serial
  • Serial ports quantity: 8
  • Serial interface type: RS-232

Design

  • Internal: Yes
  • Product colour: Yellow
  • Maximum cable length: 0.5 m
  • Mean time between failures (MTBF): 160013 h

Features

  • Chipset: ASMedia - ASM1083, System Base - SB16C1058PCI
  • Baud rate: 921.6 Kbit/s
  • FIFO (First In, First Out): 256 B
  • Data bits: 5, 6, 7, 8
  • Stop bits: 1, 1.5, 2
  • Parity bit: Even, No, Odd
  • Flow Control type: RTS/CTS, XON/XOFF

Operational conditions

  • Operating temperature (T-T): 0 - 55 °C
  • Storage temperature (T-T): -40 - 75 °C
  • Operating relative humidity (H-H): 5 - 95%

System requirements

  • Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
  • Linux operating systems supported: Yes
  • Server operating systems supported: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019

Technical details

  • Compliance certificates: RoHS

Weight & dimensions

  • Width: 16 mm
  • Depth: 105 mm
  • Height: 120 mm
  • Weight: 74 g

Packaging data

  • Cables included: Serial
  • Quick installation guide: Yes
  • Package width: 190 mm
  • Package depth: 290 mm
  • Package height: 65 mm
  • Package weight: 672 g

Logistics data

  • Harmonized System (HS) code: 84733020
  • Products per master (outer) case: 14 pc(s)
  • Master (outer) case width: 400 mm
  • Master (outer) case length: 510 mm
  • Master (outer) case height: 315 mm

Other features

  • Compliance industry standards: 16C1050 UART
