StarTech.com 4-Port Serial PCIe Card, Quad-Port PCI Express to RS232/RS422/RS485 (DB9) Serial Card, Low-Profile Bracket Incl., 16C1050 UART, Windows/Linux, TAA Compliant - Level-4 ESD Protection

$181.87
$181.87 without VAT

StarTech.com 4-Port Serial PCIe Card, Quad-Port PCI Express to RS232/RS422/RS485 (DB9) Serial Card, Low-Profile Bracket Incl., 16C1050 UART, Windows/Linux, TAA Compliant - Level-4 ESD Protection.   More info

Brand: STARTECH.COM
SKU: 104469 PRC: 505696 EAN: 65030903141 PN: PS74ADF-SERIAL-CARD

Description

StarTech.com 4-Port Serial PCIe Card, Quad-Port PCI Express to RS232/RS422/RS485 DB9 Serial Card, Standard/Low-Profile Brackets, 16C1050 UART, ESD Protection, Windows/Linux (PS74ADF-SERIAL-CARD)

Specifications

Ports & interfaces

  • Host interface: PCIe
  • Output interface: Serial
  • Serial ports quantity: 4
  • Serial interface type: RS-232/422/485

Design

  • Internal: Yes
  • Product colour: Black
  • LED indicators: Activity

Features

  • Chipset: ASIX - AX99100
  • Baud rate: 921.6 Kbit/s
  • FIFO (First In, First Out): 256 B
  • Data bits: 5, 6, 8, 9
  • Stop bits: 1, 1.5, 2
  • Flow control support: Yes
  • Parity bit: Even, Mark, No, Odd, Space

Operational conditions

  • Operating temperature (T-T): 0 - 70 °C
  • Storage temperature (T-T): -20 - 80 °C
  • Operating relative humidity (H-H): 20 - 80%

System requirements

  • Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
  • Linux operating systems supported: Yes
  • Server operating systems supported: Windows Server 2016, Windows Server 2019, Windows Server 2022

Technical details

  • Sustainability compliance: Yes
  • Compliance certificates: RoHS, Trade Agreements Act (TAA)

Weight & dimensions

  • Width: 109 mm
  • Depth: 121 mm
  • Height: 16 mm
  • Weight: 60 g

Packaging data

  • Cables included: Ribbon cable
  • Mounting brackets included: Yes
  • User guide: Yes
  • Package width: 144 mm
  • Package depth: 207 mm
  • Package height: 38 mm
  • Package weight: 273.2 g

Logistics data

  • Products per master (outer) case: 50 pc(s)
  • Master (outer) case width: 685 mm
  • Master (outer) case length: 345 mm
  • Master (outer) case height: 306 mm

Other features

  • Cable length: 0.3 m
  • Electrostatic Discharge (ESD) protection: 15 kV
