Silverstone ST45SF power supply unit 450 W 20+4 pin ATX SFX Black

$86.65
$86.65 without VAT

More info

Brand: SILVERSTONE
SKU: 84645 PRC: 288019 EAN: 4710007224298 PN: sst-st45sf v 3.0

Description

Specifications

Power

  • Total power: 450 W
  • AC input voltage: 90 - 264 V
  • AC input frequency: 47 - 63 Hz
  • Power factor: 0.9
  • Power Factor Correction (PFC) type: Active
  • Combined power (+3.3V): 110 W
  • Combined power (+12V): 450 W
  • Combined power (+5V): 110 W
  • Combined power (-12V): 3.6 W
  • Combined power (+5Vsb): 15 W
  • Max output current (+3.3V): 20 A
  • Max output current (+12V): 37.5 A
  • Max output current (+5V): 20 A
  • Max output current (-12V): 0.3 A
  • Max output current (+5Vsb): 3 A
  • Efficiency: 85%
  • Power protection features: Over current, Over power, Over voltage, Short circuit, Under voltage

Ports & interfaces

  • Motherboard power connector: 20+4 pin ATX
  • Motherboard power cable length: 30 cm
  • Number of SATA power connectors: 3
  • SATA power cable length: 220, 100, 300 mm
  • Peripheral (Molex) power connectors (4-pin): 2
  • Peripheral (Molex) power cable length: 200, 300 mm
  • EPS power connector (8-pin): Yes
  • PCI Express power connectors (6-pin): 1
  • PCI Express power connectors (6+2 pin): 1
  • PCI Express power cable length: 40 cm
  • Floppy drive power connector: 1
  • Floppy disk drive connector: Yes
  • Floppy disk drive cable length: 30 cm
  • Cabling type: Non-Modular

Performance

  • 80 PLUS certification: 80 PLUS Bronze
  • Purpose: PC
  • Power supply unit (PSU) form factor: SFX
  • ATX version: 2.4
  • Noise level: 18 dB
  • Mean time between failures (MTBF): 100000 h

Design

  • Product colour: Black
  • Cooling type: Active
  • Fan diameter: 9.2 cm
  • Number of fans: 1 fan(s)
  • Fan location: Top
  • On/off switch: Yes

Operational conditions

  • Operating temperature (T-T): 0 - 40 °C

Weight & dimensions

  • Width: 125 mm
  • Depth: 100 mm
  • Height: 63.5 mm
  • Weight: 1.1 kg

Logistics data

  • Harmonized System (HS) code: 84733020

Other features

  • Rise time: 20 ms
