Description
Mercusys MS110CP Fast Ethernet switch with 10 RJ-45 ports at 10/100 Mbit/s, powered via Power over Ethernet (PoE) compliant with IEEE 802.3af and 802.3at standards, in a black metal housing that facilitates integration into fixed installations. This unit includes auto-negotiation, flow control, full and half duplex transmission, as well as auto MDI/MDI-X, with a MAC address table of 2000 entries and jumbo frame support to optimise data transfer. With a switching capacity of 5.6 Gbit/s and a maximum transmission distance of 0.25 km, it is designed to connect multiple network devices at a single point without the need for an additional power supply for each unit.
Specifications
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 10
- Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Network
- Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
- 10G support: No
- Full duplex: Yes
- Half duplex: Yes
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Ethernet LAN data rates: 10,100 Mbit/s
- Auto-negotiation: Yes
Optical fiber
- Transmission distance (max): 0.25 km
Data transmission
- Switching capacity: 5.6 Gbit/s
- MAC address table: 2000 entries
- Jumbo frames support: Yes
- Jumbo frames: 2
Design
- Rack mounting: No
- Stackable: No
- Product colour: Black
- Housing material: Metal
- Wall mountable: Yes
Power
- Power source: DC/PoE
- Power supply included: Yes
- AC input voltage: 220 V
- AC input frequency: 50 Hz
- DC input voltage: 53.5 V
- Input current: 1.31 A
- Power consumption (typical): 3.5 W
- Power consumption (max): 74.93 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) type supported: PoE+
- Power over Ethernet plus (PoE+) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 65 W
Operational conditions
- Operating temperature (T-T): -10 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 5 - 90%
- Storage relative humidity (H-H): 10 - 95%
- Heat dissipation: 255.51 BTU/h
Weight & dimensions
- Width: 171 mm
- Depth: 98 mm
- Height: 27 mm
Packaging content
- Cables included: AC
- Quick start guide: Yes
