Return

Description

Specifications

Management features


  • Switch type: Unmanaged
  • Quality of Service (QoS) support: Yes

Ports & interfaces


  • Basic switching RJ-45 Ethernet ports quantity: 8
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Power connector: DC-in jack

Network


  • Networking standards: IEEE 802.3, IEEE 802.3ac, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
  • 10G support: No
  • Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
  • Cable types supported: Cat3, Cat4, Cat5, Cat5e
  • Full duplex: Yes
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes

Data transmission


  • Switching capacity: 16 Gbit/s
  • MAC address table: 8000 entries
  • Store-and-forward: Yes
  • Packet forwarding rate (1 Gbps): 14880 pps
  • Packet forwarding rate (100 Mbps): 148800 pps
  • Packet forwarding rate (10 Mbps): 1488000 pps
  • Packet buffer memory: 0.256 MB

Design


  • Product colour: Black
  • LED indicators: Activity, Link, PoE, Power, Speed, Status

Performance


  • Noise level: 0 dB

Power


  • Power supply included: Yes
  • Input current: 1.5 A

Power over Ethernet (PoE)


  • Power over Ethernet (PoE): Yes
  • Power over Ethernet (PoE) ports quantity: 4
  • Power over Ethernet (PoE) power per port: 30 W
  • Total Power over Ethernet (PoE) budget: 68 W

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 0 - 95%

Weight & dimensions


  • Height: 38 mm
  • Width: 190 mm
  • Depth: 120 mm
