Description
The Mercusys MS105GS unmanaged switch offers five RJ-45 Gigabit Ethernet ports (10/100/1000) in black, with DC input connectors for power supply. This model features auto-negotiation and auto MDI/MDI-X functions, making it easy to connect devices directly without configuration. Additionally, it supports flow control and full-duplex and half-duplex transmission, along with a MAC address table of 2000 entries and jumbo frames of up to 9000 bytes. Its switching capacity reaches 10 Gbit/s and it complies with IEEE 802.3, 802.3ab, 802.3p, 802.3u and 802.3x standards for reliable integration.
Specifications
Management features
- Switch type: Unmanaged
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 5
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Power connector: DC-in jack
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Full duplex: Yes
- Half duplex: Yes
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
Optical fiber
- Transmission distance (max): 0.1 km
Data transmission
- Jumbo frames: 9000
- Packet buffer memory: 0.125 MB
- Switching capacity: 10 Gbit/s
- MAC address table: 2000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
Design
- Rack mounting: No
- Stackable: No
- Product colour: Black
- Housing material: Metal
- LED indicators: Yes
- Wall mountable: Yes
Performance
- Fanless: Yes
Power
- Power source: DC
- Power supply included: Yes
- AC input voltage: 220 V
- AC input frequency: 50/60 Hz
- DC input voltage: 5 V
- Input current: 0.6 A
- Power consumption (max): 3.614 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 95%
- Heat dissipation: 12.331 BTU/h
Weight & dimensions
- Width: 99.8 mm
- Depth: 98 mm
- Height: 25.1 mm
Packaging content
- Cables included: AC
- Quick start guide: Yes
Certificates
- Certification: CE, RoHS
