Lindy 50m Cat.6 HDMI & IR Extender with PoC & Loop Out

Few units

Lindy 50m Cat.6 HDMI & IR Extender with PoC & Loop Out

Name: Lindy 50m Cat.6 HDMI & IR Extender with PoC & Loop Out
Brand: LINDY
Price: 55 EUR
Availability: InStock

55.00 €

45.46 € without VAT

More info

Amount

Brand: LINDY

SKU: 118221 PRC: 603009 EAN: 4002888385091 PN: 38509

Description

Specifications

Features

Type: AV transmitter & receiver
Maximum resolution: 1920 x 1200 pixels
Cable types supported: Cat5e, Cat6
Maximum transfer distance: 50 m
Chipset: GSV100T
Maximum refresh rate: 60 Hz
Audio output channels: 7.1 channels
Infrared (IR) frequency range: 20 - 60 kHz
Supported video modes: 1080p
Bandwidth: 4.95 Gbit/s
Video compression formats: H.265
HDCP: Yes
Material: Metal
HDCP version: 1.4
Product colour: Black
Certification: CE, FCC, RoHS, REACH & California Proposition 65

Ports & interfaces

Connectivity technology: Wired
RJ-45 input ports: 1
RJ-45 output ports: 1
HDMI in: 1
Number of HDMI outputs: 2
Video in: 1
Video out: 2
Remote (IR) input: 1
Remote (IR) output: 1
DC-in jack: Yes

Power

Operating voltage (transmitter): 5 V
Output current: 1 A
Operating voltage (receiver): 5 V

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 20 - 90%

Weight & dimensions

Receiver dimensions (WxDxH): 96 x 20 x 68 mm
Receiver weight: 440 g
Transmitter dimensions (WxDxH): 96 x 20 x 68 mm
Transmitter weight: 440 g

Packaging data

Quantity per pack: 1 pc(s)
Package width: 215 mm
Package depth: 135 mm
Package height: 75 mm
Package weight: 610 g
Package type: Box

Packaging content

AC adapter included: Yes
Manual: Yes

Technical details

Special features: PoC (Power over Cable), IR pass-through, Loop Out
Sustainability compliance: Yes
Compliance certificates: CE, Federal Communications Commission (FCC), REACH, RoHS
