Description
The Lindy 38262 is an audio and video extender that works as an AV signal transmitter and receiver, in black. It allows distribution of the HDMI 2.0 signal with one input and five outputs, reaching a maximum resolution of 3840 x 2160 pixels at 60 Hz. Its bandwidth of 18 Gbit/s guarantees a stable data flow, and HDCP 2.2 support ensures compatibility with protected content. Transmission is carried out via Cat6 cable up to a maximum distance of 70 m, which is practical for installations where the source and the display are separated. It incorporates GSV2006 and GSV5100 chipsets, and manages full-screen identification information (EDID) to adapt the signal to each display. As for audio, it supports the LPCM format. The casing is metal and features a DC input connector, as well as CE, UKCA, FCC, RoHS, REACH and California Proposition 65 certifications.
Specifications
Features
- Type: AV transmitter & receiver
- Maximum resolution: 3840 x 2160 pixels
- Cable types supported: Cat6
- Maximum transfer distance: 70 m
- Chipset: GSV2006, GSV5100
- Maximum refresh rate: 60 Hz
- Extended display identification data (EDID): Yes
- Bandwidth: 18 Gbit/s
- Audio formats supported: LPCM
- HDCP: Yes
- Material: Metal
- HDCP version: 2.2
- Product colour: Black
- Certification: CE, UKCA, FCC, RoHS, REACH & California Propositon 65
Ports & interfaces
- Connectivity technology: Wired
- RJ-45 input ports: 4
- RJ-45 output ports: 4
- HDMI in: 1
- Number of HDMI outputs: 5
- HDMI version: 2.0
- Remote (IR) input: 4
- Remote (IR) output: 1
- DC-in jack: Yes
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -10 - 80 °C
- Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
- Receiver dimensions (WxDxH): 100 x 88 x 23 mm
- Receiver weight: 199 g
- Transmitter dimensions (WxDxH): 180 x 103 x 23 mm
- Transmitter weight: 390 g
Packaging data
- Package width: 423 mm
- Package depth: 60 mm
- Package height: 354 mm
- Package weight: 2 kg
- Package type: Box
Packaging content
- Cables included: IR, IR sensor
- Manual: Yes
- Mounting brackets included: Yes
