Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- ARP inspection: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports type: No
- Combo SFP ports quantity: 4
- SFP module slots quantity: 20
- SFP+ module slots quantity: 4
- Fiber optic connector: SFP
- Console port: RJ-45
Network
- Networking standards: IEEE 802.1D, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3x, IEEE 802.3z
- 10G support: Yes
- Full duplex: Yes
- Link aggregation: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- VLAN support: Yes
- Virtual LAN features: Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, IP subnet–based VLAN
Optical fiber
- Fiber ethernet cabling technology: 10GBASE-ER, 10GBASE-LR, 10GBASE-SR, 1000BASE-LHX, 1000BASE-SX, 1000BASE‑LX, 1000BASE‑ZX
Data transmission
- Switching capacity: 128 Gbit/s
- Forwarding rate: 95 Mpps
- MAC address table: 16000 entries
- Static route: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9000
Security
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Static port security: Yes
- Loop protection: Yes
- Authentication: MAC-based authentication, Port-based authentication, Web-based authentication
- Packet filtering: CDP/PVST+
Protocols
- Management protocols: CLI, WEB, TELNET
- GARP VLAN Registration Protocol (GVRP): Yes
- IPv4 & IPv6 features: Dual stack IPv4/IPv6
Design
- Rack mounting: Yes
- Product colour: Black
- LED indicators: Diagnostic, Link, Power
- Safety: UL (UL60950-1)
Performance
- Memory type: DRAM
- Internal memory: 512 MB
- Flash memory: 256 MB
- Telnet: Yes
- Mean time between failures (MTBF): 298951 h
Power
- Redundant power supply (RPS) support: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input voltage: 48 - 60 V
- Power consumption (typical): 21.48 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 440 mm
- Depth: 220 mm
- Height: 44 mm
- Weight: 2.82 kg
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Packaging data
- Package type: Box
- Resource CD: Yes
- Package width: 580 mm
- Package depth: 405 mm
- Package height: 80 mm
- Package weight: 3.77 kg
Certificates
- Certification: CE, FCC, CISPR, BSMI
Logistics data
- Country of origin: China
- Master (outer) case width: 600 mm
- Master (outer) case length: 435 mm
- Master (outer) case height: 340 mm
- Harmonized System (HS) code: 85176990
- Master (outer) case gross weight: 16.6 kg
- Products per master (outer) case: 4 pc(s)
