Extreme networks 5520 Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Purple

Not avaliable

More info

Brand: EXTREME NETWORKS
SKU: 114541 PRC: 342429 EAN: 644728046966 PN: 5520-24t

Description

Specifications

Management features

  • Switch type: Managed
  • Switch layer: L2/L3
  • Quality of Service (QoS) support: Yes

Ports & interfaces

  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Gigabit Ethernet (copper) ports quantity: 24
  • Console port: RJ-45/Micro-USB
  • QSFP28 ports quantity: 2
  • USB 2.0 ports quantity: 2

Network

  • Networking standards: IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3aq, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bm, IEEE 802.3by, IEEE 802.3bz
  • 10G support: No
  • Copper ethernet cabling technology: 1000BASE-T
  • Full duplex: Yes
  • Half duplex: Yes
  • Ethernet LAN data rates: 10,100,1000 Mbit/s
  • Auto-sensing: Yes
  • VLAN support: Yes

Data transmission

  • Switching capacity: 648 Gbit/s
  • Forwarding rate: 482.1 Mpps

Security

  • Access Control List (ACL): Yes

Multicast features

  • Multicast support: Yes

Protocols

  • Supported network protocols: IPv4, IPv6

Design

  • Rack mounting: Yes
  • Stackable: Yes
  • Form factor: 1U
  • Product colour: Purple
  • Number of fans: 2 fan(s)

Performance

  • Noise level: 39.6 dB

Power

  • Power supply included: Yes
  • Number of power supply units: 1
  • AC input voltage: 100 - 240 V
  • AC input frequency: 47/63 Hz
  • Power consumption (typical): 52 W
  • Power consumption (max): 142 W

Power over Ethernet (PoE)

  • Power over Ethernet (PoE): No

Operational conditions

  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 95%
  • Storage relative humidity (H-H): 10 - 95%
  • Operating altitude: 0 - 3000 m
  • Heat dissipation: 176 BTU/h

Weight & dimensions

  • Width: 441 mm
  • Depth: 442 mm
  • Height: 44 mm
  • Weight: 5.54 kg

Sustainability

  • Sustainability compliance: Yes

Certificates

  • Compliance certificates: REACH, RoHS, WEEE
  • Certification: EN/ETSI 300 019-2-1 v2.1.2, UL 60950-1, UL/CuL 62368-1, FCC 21CFR 1040.10, CDRH, CAN/CSA 22.2 No. 60950-1, EN 60950-1, EN 62368-

Logistics data

  • Harmonized System (HS) code: 85176990
