Extreme networks 5320-16P-4XE network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Purple

Not avaliable

More info

Brand: EXTREME NETWORKS
SKU: 96754 PRC: 397822 EAN: 644728053261 PN: 5320-16P-4XE

Description

Specifications

Management features

  • Switch type: Managed
  • Switch layer: L2
  • Quality of Service (QoS) support: Yes
  • Web-based management: Yes
  • Cloud-managed: Yes
  • ARP inspection: Yes
  • Configuring Location Settings (CLI): Yes

Ports & interfaces

  • Basic switching RJ-45 Ethernet ports quantity: 16
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • SFP module slots quantity: 4
  • Console port: RJ-45/USB Type-B
  • USB 2.0 ports quantity: 1

Network

  • Networking standards: IEEE 802.3at
  • 10G support: Yes
  • Copper ethernet cabling technology: 1000BASE-T
  • Full duplex: Yes
  • IP routing: Yes
  • Half duplex: Yes
  • IP address table: 16000
  • Ethernet LAN data rates: 10,100,1000 Mbit/s
  • Auto-sensing: Yes
  • IPv4 routes: 12000
  • IPv6 routes: 6000
  • VLAN support: Yes
  • Number of VLANs: 4094

Data transmission

  • Switching capacity: 112 Gbit/s
  • Forwarding rate: 83.3 Mpps
  • MAC address table: 32000 entries
  • Number of queues: 8

Security

  • Access Control List (ACL): Yes
  • Access Control List (ACL) egress: 1024
  • Access Control List (ACL) ingress: 8000

Multicast features

  • Multicast support: Yes
  • IPv4 multicast entries: 6000

Design

  • Rack mounting: Yes
  • Stackable: Yes
  • Product colour: Purple

Performance

  • Noise level: 29.4 dB

Power

  • Power source: AC
  • Power supply included: Yes
  • Number of power supply units: 1
  • Power consumption (max): 246 W

Power over Ethernet (PoE)

  • Power over Ethernet (PoE): Yes
  • Power over Ethernet (PoE) ports quantity: 16
  • Power over Ethernet (PoE) power per port: 30 W
  • Total Power over Ethernet (PoE) budget: 185 W

Operational conditions

  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 95%
  • Storage relative humidity (H-H): 10 - 95%
  • Operating altitude: 0 - 3000 m
  • Heat dissipation: 208 BTU/h

Weight & dimensions

  • Width: 310 mm
  • Depth: 43.6 mm
  • Height: 300 mm
  • Weight: 3 kg

Sustainability

  • Sustainability compliance: Yes

Certificates

  • Compliance certificates: REACH, RoHS, WEEE
