Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Cloud-managed: Yes
- ARP inspection: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 48
- SFP+ module slots quantity: 4
- USB Type-C ports quantity: 1
- Console port: RJ-45
- USB 2.0 ports quantity: 1
Network
- Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
- 10G support: Yes
- Port mirroring: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- VLAN support: Yes
- Virtual LAN features: MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
- Number of VLANs: 4000
Data transmission
- Switching capacity: 176 Gbit/s
- Forwarding rate: 130.94 Mpps
- MAC address table: 16000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Packet buffer memory: 12 MB
Security
- DHCP features: DHCP relay, DHCP server
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Security algorithms: SNMP, SNMPv2, SNMPv3
- MAC address filtering: Yes
- Static port security: Yes
- SSH/SSL support: Yes
- IP-MAC-Port binding: Yes
- Password protection: Yes
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Stackable: Yes
- Product colour: Black
- LED indicators: Yes
Performance
- Physical stacking (units): 4
- Built-in processor: Yes
- Processor manufacturer: ARM
- Processor frequency: 1200 MHz
- Memory type: DRAM
- Internal memory: 2000 MB
- Flash memory: 512 MB
- Firmware upgradeable: Yes
- Telnet: Yes
- Fanless: Yes
- Mean time between failures (MTBF): 211.644 h
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Power consumption (max): 34.1 W
- Surge protection: Yes
- Surge protection voltage: 6 kV
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Other features
- Management level: 4
- Bandwidth: 88 Gbit/s
Operational conditions
- Operating temperature (T-T): -5 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 116.42 BTU/h
Weight & dimensions
- Width: 440 mm
- Depth: 220 mm
- Height: 44 mm
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Certificates
- Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
