Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- System event log: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Auto MDI/MDI-X: Yes
- Spanning tree protocol: Yes
- Head-of-line (HOL) blocking: Yes
- Auto-negotiation: Yes
- VLAN support: Yes
- Virtual LAN features: Port-based VLAN, Voice VLAN
- Number of VLANs: 128
- Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 10BASE-TX, 1000BASE-T
Data transmission
- Switching capacity: 48 Gbit/s
- Forwarding rate: 35.71 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
- Number of queues: 4
- Jumbo frames support: Yes
- Jumbo frames: 9216
- Packet buffer memory: 4.1 MB
Security
- DHCP features: DHCP client
- IGMP snooping: Yes
- Security algorithms: SNMP, SSL/TLS
- Queue scheduling algorithms: SPQ, Weighted Round Robin (WRR)
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Product colour: Black
- LED indicators: Yes
Performance
- Built-in processor: Yes
- Processor frequency: 125 MHz
- Memory type: DRAM
- Flash memory: 16 MB
- Noise level: 0 dB
- Fanless: Yes
- Mean time between failures (MTBF): 255003 h
Power
- AC input voltage: 100 - 240 V
- Power consumption (max): 19.5 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 12
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 100 W
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 2000 m
- Heat dissipation: 107.5 BTU/h
Weight & dimensions
- Width: 280 mm
- Depth: 230 mm
- Height: 44 mm
- Weight: 2.2 kg
Certificates
- Certification: EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC
Logistics data
- Harmonized System (HS) code: 85176990
