Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- ARP inspection: Yes
- System event log: Yes
- MIB support: RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2573, RFC2575, RFC2576, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, FC
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP module slots quantity: 2
- Fiber optic connector: SFP
Network
- Networking standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Cable types supported: Cat5, Cat5e
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Auto MDI/MDI-X: Yes
- Spanning tree protocol: Yes
- Head-of-line (HOL) blocking: Yes
- VLAN support: Yes
- Number of VLANs: 4094
Optical fiber
- Fiber ethernet cabling technology: 100BASE-FX, 1000BASE-X
Data transmission
- Switching capacity: 20 Gbit/s
- Forwarding rate: 14.88 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 10000
- Packet buffer memory: 4.1 MB
Security
- DHCP features: DHCP server, DHCP client
- Access Control List (ACL): Yes
- Access Control List (ACL) rules: 768
- IGMP snooping: Yes
- Security algorithms: 802.1x RADIUS, EAP, MD5, PEAP, SNMP, SSH-2, SSL/TLS, TTLS
- Loop protection: Yes
- IP-MAC-Port binding: Yes
Multicast features
- Multicast support: Yes
Design
- Product colour: Black
- LED indicators: Activity, Link, Power, Speed
- Safety: CB, UL, BSMI, CCC
Performance
- Memory type: DDR3-SDRAM
- Internal memory: 128 MB
- Flash memory: 32 MB
- Noise level: 0 dB
- Firmware upgradeable: Yes
- Maximum cable length: 100 m
- Mean time between failures (MTBF): 1274005 h
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 152.3 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 130 W
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Heat dissipation: 519.51 BTU/h
Weight & dimensions
- Width: 330 mm
- Depth: 180 mm
- Height: 44 mm
- Weight: 1.77 kg
Packaging data
- Package width: 319 mm
- Package depth: 400 mm
- Package height: 91 mm
- Package weight: 3.1 kg
Technical details
- Shipping (inner) case height: 34.9 cm
- Shipping (inner) case width: 29.4 cm
- Shipping (inner) case length: 41.6 cm
- Shipping (inner) case net weight: 9.31 kg
- Products per shipping (inner) case: 3 pc(s)
- Pallet gross weight (air): 268.3 kg
- Master (outer) cases per pallet (air): 24 pc(s)
- Products per pallet (air): 72 pc(s)
- Pallet gross length: 110 cm
- Pallet gross width: 120 cm
- Pallet height (air): 118.2 cm
- Pallet gross weight (sea): 430.6 kg
- Master (outer) cases per pallet (sea): 40 pc(s)
- Products per pallet (sea): 120 pc(s)
- Pallet height (sea): 188 cm
- Shipping (inner) case gross weight: 10.1 kg
Certificates
- Certification: CE A, VCCI A, FCC A, BSMI, CCC
Logistics data
- Harmonized System (HS) code: 85176990
