Description
The managed switch Cudy GS2008S2, in a black 1U form factor, offers eight Gigabit Ethernet RJ-45 ports (10/100/1000) and two SFP modules for fibre links. Its L2 layer management includes VLAN support with up to 4096 virtual networks, including Voice VLAN, and spanning tree protocol to prevent network loops. Management is conveniently carried out from a web browser, with QoS features to prioritise traffic, link aggregation and storm control to maintain stability. It also includes traffic classification and system event logging, being compatible with Cat3, Cat4 and Cat5 cables.
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Traffic classification: Yes
- System event log: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 8
- Installed SFP modules quantity: 2
- Console port: RJ-45
Network
- Networking standards: IEEE 802.11j, IEEE 802.11k, IEEE 802.1Qav
- Cable types supported: Cat3, Cat4, Cat5
- Port mirroring: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Spanning tree protocol: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
- VLAN support: Yes
- Virtual LAN features: Voice VLAN
- Number of VLANs: 4096
Optical fiber
- Fiber type: Multi-mode
Data transmission
- Switching capacity: 56 Gbit/s
- Forwarding rate: 41.66 Mpps
- MAC address table: 8000 entries
- Static route: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9.6
- Packet buffer memory: 0.5 MB
Security
- DHCP features: DHCP Option 82, DHCP server, DHCP snooping
- IGMP snooping: Yes
- SSH/SSL support: Yes
- IP-MAC-Port binding: Yes
- Authentication: Port-based authentication
- Authentication type: RADIUS, TACACS+
Multicast features
- Multicast support: Yes
Protocols
- IPv4 & IPv6 features: IPv6 Telnet
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: Activity, Link, Power, System
Performance
- Memory type: DDR-SDRAM
- Internal memory: 128 MB
- Flash memory: 16 MB
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
Operational conditions
- Storage relative humidity (H-H): 5 - 90%
- Operating temperature (T-T): -10 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 268 mm
- Depth: 181 mm
- Height: 44 mm
- Weight: 1.01 kg
Packaging data
- Package type: Box
- Package width: 312 mm
- Package depth: 262 mm
- Package height: 84 mm
- Package weight: 1.54 kg
