Asustor Lockerstor 10 AS6510T NAS Tower Intel Atom® C3538 8 GB DDR4 0 TB ADM Black

Name: Asustor Lockerstor 10 AS6510T NAS Tower Intel Atom® C3538 8 GB DDR4 0 TB ADM Black
Brand: ASUSTOR
SKU: 272431
Price: 1290.66 EUR
Availability: InStock

More info

Brand: ASUSTOR

1,290.66 €

1,066.66 € without VAT

Stock available: 2 units.

Get it on the September 4 / September 7

SKU: 83625 PRC: 272431 EAN: 4710474831227 PN: as6510t

Description

This Asustor Lockerstor 10 AS6510T tower NAS arrives without preinstalled drives (0 TB), so you can configure storage to your needs with its 10 bays compatible with 2.5 or 3.5-inch HDD and SSD drives, plus two internal M.2 slots. The Intel Atom C3538 processor and its 8 GB of DDR4 memory manage RAID 0, 1, 5, 6, 10 and JBOD levels, with online volume migration and expansion without service interruption. It supports file systems such as BTRFS, NTFS, exFAT or ext4, and includes bad sector detection to monitor drive health. Its black tower design is ready to integrate into your local network via its SATA III connections.

Specifications

Storage

Storage drive capacity: 0 GB
Supported storage drive interfaces: Serial ATA III
Storage drive sizes supported: 2.5, 3.5, M.2
Number of M.2 (M & B) slots: 2
RAID support: Yes
RAID levels: 0, 1, 5, 6, 10, JBOD
Online RAID migration: Yes
Online RAID expansion: Yes
Supported file systems: BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drives installed: No
Total installed storage capacity: 0 TB
Number of storage drives supported: 10
Installed storage drive type: No
Supported storage drive types: HDD & SSD
Bad block scan: Yes

Processor

Processor manufacturer: Intel
Processor family: Intel Atom®
Processor model: C3538
Processor frequency: 2.1 GHz
Processor cores: 4
Processor threads: 4
Processor cache: 8 MB
CPU configuration (max): 1
PCI Express slots version: 3.0
Processor cache type: Smart Cache
Processor code: SR3L7
Processor codename: Denverton
Processor lithography: 14 nm
Processor operating modes: 64-bit
Processor package size: 34 x 28 mm
Processor socket: BGA 1310
Stepping: B1
Tcase: 87 °C
Tjunction: 100 °C
Thermal Design Power (TDP): 15 W
Maximum internal memory supported by processor: 256 GB
Conflict-Free processor: Yes

Memory

Internal memory: 8 GB
Internal memory type: DDR4
Memory clock speed: 2133 MHz
Maximum RAM supported: 64 GB
Memory slots: 2
Memory form factor: SO-DIMM
Flash memory: 4096 MB

Network

Ethernet LAN: Yes
Ethernet LAN data rates: 100, 1000, 2500, 10000 Mbit/s
Ethernet LAN data rate supported (max): 10000 Mbit/s
DHCP server: Yes
Jumbo frames support: Yes
iSCSI support: Yes
Wake-on-LAN ready: Yes
Supported network protocols: TCP/IP (IPv4 & IPv6), CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP, TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy
Link aggregation: Yes
Load balancing system: Yes
Dynamic DNS (DDNS): Yes
WLAN adapter supported: Yes

Ports & interfaces

USB port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 4

Design

Chassis type: Tower
Cooling type: Active
Product colour: Black
Number of fans: 2 fan(s)
Fan diameter: 12 cm
Built-in display: Yes
Display type: LCD

Performance

Type: NAS
Device class: Home & Home Office
Backup function: Yes
Backup features: Cloud, iSCSI LUN
Multilingual support: Yes
Number of users: 4096 user(s)
Noise level (idle): 22 dB
Snapshot: Yes
Web-based management: Yes
Share folder access right management: Yes
Security algorithms: 256-bit AES, HTTPS, SSH, SSL/TLS
Access Control List (ACL): Yes
Reset button: Yes
Built-in UPnP AV media server: Yes
Built-in iTunes server: Yes
Browser supported: Internet Explore 11+, FireFox, Chrome, Safari, Microsoft Edge
System log: Yes
Disk scan: Yes
S.M.A.R.T. support: Yes
Share folder: Windows ACL
Universal Plug and Play (UPnP): Yes

Software

Operating system installed: ADM
Operating system version: 3.4
Windows operating systems supported: Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported: Yes
Mac operating systems supported: Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac
Server operating systems supported: Windows Server 2003, Windows Server 2008, Windows Server 2012
Other operating systems supported: Linux
