Description
The compact Asustor FS6706T NAS storage server in black integrates an Intel® Celeron® N5105 processor with four cores and four threads at a turbo frequency of 2.9 GHz, along with 4 GB of DDR4 memory. This model supports six SSD drives with an M.2 interface, although it does not include installed drives, and offers compatibility with RAID levels 0, 1, 5, 6, and 10, including online RAID reconstruction, migration, and expansion. It supports file systems such as BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, and ext4 for flexibility in data management. Its compact design facilitates integration into small work environments, while the maximum CPU configuration is a single processor.
Specifications
Storage
- Storage drive interface: M.2
- Supported storage drive interfaces: M.2
- RAID support: Yes
- RAID levels: 0, 1, 5, 6, 10
- Online RAID migration: Yes
- Online RAID expansion: Yes
- RAID rebuild: Yes
- Supported file systems: BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
- Storage drives installed: No
- Number of storage drives supported: 6
- Installed storage drive type: No
- Supported storage drive types: SSD
Processor
- Processor manufacturer: Intel
- Processor family: Intel® Celeron®
- Processor model: N5105
- Processor frequency: 2 GHz
- Processor boost frequency: 2.9 GHz
- Processor cores: 4
- Processor threads: 4
- Processor cache: 4 MB
- CPU configuration (max): 1
Memory
- Internal memory: 4 GB
- Internal memory type: DDR4
- Maximum RAM supported: 16 GB
- Memory slots: 2
- Memory form factor: SO-DIMM
- Flash memory: 8 MB
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 100, 1000, 2500 Mbit/s
- Jumbo frames support: Yes
- Wake-on-LAN ready: Yes
- Supported network protocols: CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy,
- Link aggregation: Yes
- Dynamic DNS (DDNS): Yes
- WLAN adapter supported: Yes
Ports & interfaces
- USB port: Yes
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- HDMI ports quantity: 1
- HDMI version: 2.0b
- Ethernet LAN (RJ-45) ports: 2
- Audio in/out: Yes
Design
- Chassis type: Compact
- Cooling type: Active
- Product colour: Black
- Number of fans: 1 fan(s)
- Fan diameter: 8 cm
- LED indicators: Yes
Performance
- Type: NAS
- Device class: Home & Home Office
- Backup function: Yes
- Backup features: Cloud, USB drive
- Multilingual support: Yes
- Number of users: 4096 user(s)
- Noise level: 18.7 dB
- Third-party support: Yes
- Snapshot: Yes
- Web-based management: Yes
- Share folder access right management: Yes
- Security algorithms: FTPES, HTTPS, SSH, SSL/TLS
- Access Control List (ACL): Yes
- Built-in BitTorrent client: Yes
- Built-in iTunes server: Yes
- Built-in FTP server: Yes
- Browser supported: Firefox, Chrome, Safari, Microsoft Edge
- Network Time Protocol (NTP) client: Yes
- System log: Yes
- Password authentication: Yes
- Disk scan: Yes
- S.M.A.R.T. support: Yes
- Remotely operated: Yes
Software
- Windows operating systems supported: Yes
- Linux operating systems supported: Yes
- Mac operating systems supported: Yes
- Other operating systems supported: Android, iOS
Power
- Power supply location: External
- Power supply unit (PSU) capacity: 65 W
- Power consumption (typical): 18.2 W
- Power consumption (sleep): 0.83 W
- AC input voltage: 100-240 V
Weight & dimensions
- Width: 308.3 mm
- Depth: 193 mm
- Height: 48.3 mm
- Weight: 1.35 kg
Packaging content
- External power adapter: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
Other features
- Warranty period: 3 year(s)
- Compliance certificates: CCC, CE, Federal Communications Commission (FCC), KCC, UKCA
