Asustor AS6508T NAS Tower Intel Atom® C3538 8 GB DDR4 0 TB ADM Black

$962.65
$962.65 without VAT

More info

Brand: ASUSTOR
SKU: 83626 PRC: 272432 EAN: 4710474831210 PN: as6508t

Description

Specifications

Storage

  • Storage drive capacity: 0 GB
  • Supported storage drive interfaces: Serial ATA III
  • Storage drive sizes supported: 2.5, 3.5"
  • Maximum supported storage capacity: 128 TB
  • Number of M.2 (M & B) slots: 2
  • RAID support: Yes
  • RAID levels: 0, 1, 5, 6, 10, JBOD
  • Online RAID migration: Yes
  • Supported file systems: BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
  • Storage drives installed: No
  • Total installed storage capacity: 0 TB
  • Number of storage drives supported: 8
  • Installed storage drive type: No
  • Supported storage drive types: HDD & SSD

Processor

  • Processor manufacturer: Intel
  • Processor family: Intel Atom®
  • Processor model: C3538
  • Processor frequency: 2.1 GHz
  • Processor boost frequency: 2.1 GHz
  • Processor cores: 4
  • Processor threads: 4
  • Processor cache: 8 MB
  • CPU configuration (max): 1
  • PCI Express slots version: 3.0
  • Processor cache type: Smart Cache
  • Processor code: SR3L7
  • Processor codename: Denverton
  • Processor lithography: 14 nm
  • Processor operating modes: 64-bit
  • Processor package size: 34 x 28 mm
  • Processor socket: BGA 1310
  • Stepping: B1
  • Tcase: 87 °C
  • Tjunction: 100 °C
  • Thermal Design Power (TDP): 15 W
  • Maximum internal memory supported by processor: 256 GB
  • Conflict-Free processor: Yes

Memory

  • Maximum RAM supported: 32 GB
  • Memory slots: 2
  • Memory form factor: SO-DIMM
  • Flash memory: 4 MB
  • Internal memory: 8 GB
  • Internal memory type: DDR4
  • Memory clock speed: 2133 MHz

Network

  • Ethernet LAN: Yes
  • Ethernet LAN data rates: 2500, 10000 Mbit/s
  • Ethernet LAN data rate supported (max): 10000 Mbit/s
  • Wi-Fi: No
  • Jumbo frames support: Yes
  • iSCSI support: Yes
  • Wake-on-LAN ready: Yes
  • Supported network protocols: TCP/IP (IPv4 & IPv6), CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP, TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy
  • Link aggregation: Yes
  • Load balancing system: Yes
  • Dynamic DNS (DDNS): Yes

Ports & interfaces

  • USB port: Yes
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
  • Ethernet LAN (RJ-45) ports: 4

Design

  • Chassis type: Tower
  • Cooling type: Active
  • Product colour: Black
  • Number of fans: 2 fan(s)
  • Fan diameter: 12 cm
  • Built-in display: Yes
  • Display type: LCD

Performance

  • Type: NAS
  • Device class: Small & Medium Business
  • Backup function: Yes
  • Backup features: Cloud, iSCSI LUN
  • Multilingual support: Yes
  • Noise level: 22 dB
  • Snapshot: Yes
  • Web-based management: Yes
  • Share folder access right management: Yes
  • Security algorithms: 256-bit AES, HTTPS, SSH, SSL/TLS
  • Access Control List (ACL): Yes
  • Built-in UPnP AV media server: Yes
  • Built-in iTunes server: Yes
  • Browser supported: Internet Explore 11+, FireFox, Chrome, Safari, Microsoft Edge
  • System log: Yes
  • S.M.A.R.T. support: Yes

Software

  • Operating system installed: ADM
  • Operating system version: 3.1
  • Windows operating systems supported: Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
  • Linux operating systems supported: Yes
  • Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Ma
  • Server operating systems supported: Windows Server 2003, Windows Server 2008, Windows Server 2012

Power

  • Power supply location: Built-in
  • Power supply unit (PSU) capacity: 250 W
  • Number of power supply units: 1
  • Power consumption (typical): 66.9 W
  • Power consumption (HDD standby): 37.2 W
  • AC input voltage: 100 - 240 V

Weight & dimensions

  • Width: 293 mm
  • Depth: 230 mm
  • Height: 215.5 mm
  • Weight: 6.2 kg

Packaging content

  • Cables included: AC, LAN (RJ-45)
  • Quick installation guide: Yes
  • Number of screws: 66

Processor special features

  • Embedded options available: Yes
  • Execute Disable Bit: Yes
  • Intel QuickAssist Technology: Yes
  • Intel Secure Boot: Yes
  • Intel Secure Boot Technology version: 1.00
  • Intel Secure Key Technology version: 1.00
  • Intel Virtualization Technology (VT-x): Yes
  • Intel Virtualization Technology for Directed I/O (VT-d): Yes
  • Intel VT-x with Extended Page Tables (EPT): Yes
  • Intel® AES New Instructions (Intel® AES-NI): Yes
  • Intel® Hyper Threading Technology (Intel® HT Technology): No
  • Intel® OS Guard: Yes
  • Intel® Secure Key: Yes
  • Intel® Turbo Boost Technology: No
  • Maximum number of PCI Express lanes: 12
  • Memory types supported by processor: DDR4-SDRAM

Operational conditions

  • Operating temperature (T-T): 0 - 40 °C
  • Operating relative humidity (H-H): 5 - 95%

Logistics data

  • Harmonized System (HS) code: 84714100

Other features

  • Certification: FCC, CE, VCCI, BSMI, C-TICK
  • Processor ARK ID: 97929
